| Type | Datasheet | Circuit | Marking | Polarity | PCM | IC | VCBO | VCEO | VEBO | hFE | VCE | fT | Package | |
| (W) | (A) | (V) | (V) | (V) | Min | Max | (V) | (MHz) | ||||||
| 重置全部 | / | / | / |
Reset
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | ||||||||||||
| 2SD2142 | / | / | NPN | 0.2 | 0.3 | 40 | 32 | 12 | / | 5000 | 1.4 | / | SOT-23 | |
| MMBTA13 | / | / | NPN | 0.3 | 0.3 | 30 | 30 | 10 | / | 10000 | 1.5 | / | SOT-23 | |
| MMBTA14 | / | / | NPN | 0.3 | 0.3 | 30 | 30 | 10 | / | 20000 | 1.5 | / | SOT-23 | |
| MMBTA28 | / | / | NPN | 0.2 | 0.5 | 80 | 80 | 12 | / | 10000 | 1.2 | / | SOT-23 | |
| BCV47 | / | / | NPN | 0.3 | 0.5 | 80 | 60 | 10 | / | 10000 | 1 | / | SOT-23 | |
| BCV27 | / | / | NPN | 0.3 | 0.5 | 40 | 30 | 10 | / | 20000 | 1 | / | SOT-23 | |
| PZTA14 | / | / | NPN | 1 | 0.5 | 30 | 30 | 10 | / | 20000 | 1.5 | / | SOT-223 | |
| CZT122 | / | / | NPN | 1 | 5 | 100 | 100 | 5 | / | 1000 | 4 | / | SOT-223 | |
| MJD112 | / | / | NPN | 1.5 | 2 | 100 | 100 | 5 | / | 1000 | 3 | / | TO-252 | |
| MJD31C | / | / | NPN | 2 | 3 | 100 | 100 | 5 | / | 10 | 1.2 | / | TO-252 | |
| MJD41C | / | / | NPN | 2 | 6 | 100 | 100 | 5 | / | 15 | 1.5 | / | TO-252 | |
| MJD122 | / | / | NPN | 1.5 | 8 | 100 | 100 | 5 | / | 1000 | 2 | / | TO-252 | |
| TIP122 | / | / | NPN | 2 | 5 | 100 | 100 | 5 | / | 1000 | 4 | / | TO-263 | |
| TIP41C | / | / | NPN | 2 | 6 | 100 | 100 | 5 | / | 15 | 1.5 | / | TO-263 | |
| MPSA13 | / | / | NPN | 0.625 | 0.5 | 30 | 30 | 10 | / | 10000 | 1.5 | / | TO-92 | |
| MPSA14 | / | / | NPN | 0.625 | 0.5 | 30 | 30 | 10 | / | 20000 | 1.5 | / | TO-92 | |
| MPSA29 | / | / | NPN | 0.625 | 0.5 | 100 | 100 | 12 | / | 10000 | 1.5 | / | TO-92 | |
| MJD112 | / | / | NPN | 1.5 | 2 | 100 | 100 | 5 | / | 1000 | 3 | / | TO-251 | |
| MJD122 | / | / | NPN | 1.5 | 8 | 100 | 100 | 5 | / | 1000 | 2 | / | TO-251 | |
| TIP122 | / | / | NPN | 1.25 | 5 | 100 | 100 | 5 | / | 1000 | 2 | / | TO-126 | |
| TIP122F | / | / | NPN | 2 | 5 | 100 | 100 | 5 | / | 1000 | 4 | / | TO-220F | |
| TIP112 | / | / | NPN | 2 | 2 | 100 | 100 | 5 | / | 1000 | 2.5 | / | TO-220AB | |
| TIP31 | / | / | NPN | 2 | 3 | 40 | 40 | 5 | / | 10 | 1.5 | / | TO-220AB | |
| TIP31A | / | / | NPN | 2 | 3 | 60 | 60 | 5 | / | 10 | 1.5 | / | TO-220AB | |
| TIP31B | / | / | NPN | 2 | 3 | 80 | 80 | 5 | / | 10 | 1.5 | / | TO-220AB | |
| TIP31C | / | / | NPN | 2 | 3 | 100 | 100 | 5 | / | 10 | 1.5 | / | TO-220AB | |
| TIP120 | / | / | NPN | 2 | 5 | 60 | 60 | 5 | / | 1000 | 4 | / | TO-220AB | |
| TIP121 | / | / | NPN | 2 | 5 | 80 | 80 | 5 | / | 1000 | 4 | / | TO-220AB | |
| TIP122 | / | / | NPN | 2 | 5 | 100 | 100 | 5 | / | 1000 | 4 | / | TO-220AB | |
| TIP41C | / | / | NPN | 2 | 6 | 100 | 100 | 5 | / | 15 | 1.5 | / | TO-220AB | |
| MJD117 | / | / | PNP | 1.5 | -2 | -100 | -100 | -5 | / | 1000 | -3 | / | TO-252 | |
| MJD127 | / | / | PNP | 1.5 | -8 | -100 | -100 | -5 | / | 1000 | -4 | / | TO-252 | |
| PZTA64 | / | / | PNP | 1 | -0.5 | -30 | -30 | -10 | / | 20000 | -1.5 | / | SOT-223 | |
| CZT127 | / | / | PNP | 1 | -5 | -100 | -100 | -5 | / | 1000 | -4 | / | SOT-223 | |
| MJD117 | / | / | PNP | 1.5 | -2 | -100 | -100 | -5 | / | 1000 | -3 | / | TO-251 | |
| MJD127 | / | / | PNP | 1.5 | -8 | -100 | -100 | -5 | / | 1000 | -4 | / | TO-251 | |
| TIP127 | / | / | PNP | 1.25 | -5 | -100 | -100 | -5 | / | 1000 | -2 | / | TO-126 | |
| TIP127F | / | / | PNP | 2 | -5 | -100 | -100 | -5 | / | -1000 | -4 | / | TO-220F | |
| TIP117 | / | / | PNP | 2 | -2 | -100 | -100 | -5 | / | 1000 | -2.5 | / | TO-220AB | |
| TIP32C | / | / | PNP | 2 | -3 | 100 | 100 | 5 | / | 10 | 1.5 | / | TO-220AB | |
| TIP127 | / | / | PNP | 2 | -5 | -100 | -100 | -5 | / | 1000 | -4 | / | TO-220AB | |
| TIP42C | / | / | PNP | 2 | -6 | 100 | 100 | 5 | / | 15 | 1.5 | / | TO-220AB | |
| TIP147 | / | / | PNP | 2 | -10 | -100 | -100 | -5 | / | 1000 | -2 | / | TO-220AB | |
