| Type | Datasheet | Circuit | Marking | I(AV) | VRRM | IFSM | VFM | IRM @ VRRM | Trr | Package | |
| @IRM | VFM | I(AV) | TA=25℃ | ||||||||
| A | V | A | V | A | μA | nS | |||||
| 重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | |||||||||
| MDS500-08 |
|
|
YFW MDS500-08 | 500 | 800 | 5000 | 1.2 | 500 | 0.5 | 1000 | M13 |
| MDS500-10 |
|
|
YFW MDS500-10 | 500 | 1000 | 5000 | 1.2 | 500 | 0.5 | 1000 | M13 |
| MDS500-12 |
|
|
YFW MDS500-12 | 500 | 1200 | 5000 | 1.2 | 500 | 0.5 | 1000 | M13 |
| MDS500-14 |
|
|
YFW MDS500-14 | 500 | 1400 | 5000 | 1.2 | 500 | 0.5 | 1000 | M13 |
| MDS500-16 |
|
|
YFW MDS500-16 | 500 | 1600 | 5000 | 1.2 | 500 | 0.5 | 1000 | M13 |
| SKBPC1508 |
|
|
YFW SKBPC1508 | 15 | 800 | 400 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC1510 |
|
|
YFW SKBPC1510 | 15 | 1000 | 400 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC1512 |
|
|
YFW SKBPC1512 | 15 | 1200 | 400 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC1516 |
|
|
YFW SKBPC1516 | 15 | 1600 | 400 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC1518 |
|
|
YFW SKBPC1518 | 15 | 1800 | 400 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC2508 |
|
|
YFW SKBPC2508 | 25 | 800 | 360 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC2510 |
|
|
YFW SKBPC2510 | 25 | 1000 | 360 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC2512 |
|
|
YFW SKBPC2512 | 25 | 1200 | 360 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC2516 |
|
|
YFW SKBPC2516 | 25 | 1600 | 360 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC2518 |
|
|
YFW SKBPC2518 | 25 | 1800 | 360 | 1.05 | 12.5 | 10 | 1000 | SKBPC |
| SKBPC5010 |
|
|
YFW SKBPC5010 | 50 | 1000 | 500 | 1.05 | 25 | 10 | 1000 | SKBPC |
| SKBPC5012 |
|
|
YFW SKBPC5012 | 50 | 1200 | 500 | 1.05 | 25 | 10 | 1000 | SKBPC |
| SKBPC5016 |
|
|
YFW SKBPC5016 | 50 | 1600 | 500 | 1.05 | 25 | 10 | 1000 | SKBPC |
| SKBPC5018 |
|
|
YFW SKBPC5018 | 50 | 1800 | 500 | 1.05 | 25 | 10 | 1000 | SKBPC |
| SKBPC3508 |
|
|
YFW SKBPC3508 | 35 | 800 | 450 | 1.05 | 17.5 | 10 | 1000 | SKBPC |
| MT3508 |
|
|
YFW MT3508 | 35 | 800 | 400 | 1.1 | 17.5 | 5 | 1000 | MT |
| MT3510 |
|
|
YFW MT3510 | 35 | 1000 | 400 | 1.1 | 17.5 | 5 | 1000 | MT |
| MT3512 |
|
|
YFW MT3512 | 35 | 1200 | 400 | 1.1 | 17.5 | 5 | 1000 | MT |
| MT3514 |
|
|
YFW MT3514 | 35 | 1400 | 400 | 1.1 | 17.5 | 5 | 1000 | MT |
| MT3516 |
|
|
YFW MT3516 | 35 | 1600 | 400 | 1.2 | 17.5 | 5 | 1000 | MT |
| SKBPC7516 |
|
|
YFW SKBPC7516 | 75 | 1600 | 750 | 1.1 | 75 | 5 | 1000 | SKBPC-A |
| MDS200-08 |
|
|
YFW MDS200-08 | 200 | 800 | 2240 | 1.55 | 300 | 300 | 1000 | M11 |
| MDS100-16 |
|
|
YFW MDS100-16 | 100 | 1600 | 1000 | 1.2 | 100 | 10000 | 1000 | M08 |
| MDS100-06 |
|
|
YFW MDS100-06 | 100 | 600 | 1500 | 1.1 | 100 | 10000 | 1000 | M08 |
| MDS75-16 |
|
|
YFW MDS75-16 | 75 | 1600 | 700 | 1.3 | 5 | 5 | 1000 | M08 |
| MDS75-12 |
|
|
YFW MDS75-12 | 75 | 1200 | 700 | 1.3 | 5 | 5 | 1000 | M08 |
| MDS75-08 |
|
|
YFW MDS75-08 | 75 | 800 | 700 | 1.3 | 5 | 5 | 1000 | M08 |
| MDS50-16 |
|
|
YFW MDS50-16 | 50 | 1600 | 750 | 1.1 | 50 | 8000 | 1000 | M08 |
| MDS200 |
|
|
YFW MDS200 | 67 | 1600 | 2.1 | 1.35 | 200 | 15000 | 1000 | M08 |
| MDS175 |
|
|
YFW MDS175 | 58 | 1600 | 2.7 | 1.51 | 175 | 12000 | 1000 | M08 |
| MDS30 |
|
|
YFW MDS30 | 10 | 1600 | 0.5 | 1.1 | 30 | 2000 | 1000 | M08 |
| MDS50 |
|
|
YFW MDS50 | 17 | 1600 | 0.75 | 1.2 | 50 | 4000 | 1000 | M08 |
| MDS75 |
|
|
YFW MDS75 | 25 | 1600 | 1 | 1.25 | 75 | 4000 | 1000 | M08 |
| MDS100 |
|
|
YFW MDS100 | 33 | 1600 | 1.2 | 1.3 | 100 | 8000 | 1000 | M08 |
| MDS150 |
|
|
YFW MDS150 | 50 | 1600 | 1.5 | 1.2 | 150 | 10000 | 1000 | M08 |
| MDS250-16 |
|
|
YFW MDS250-16 | 250 | 1600 | 2800 | 1.45 | 250 | 20 | 1000 | MDS |
| MDS250-12 |
|
|
YFW MDS250-12 | 250 | 1200 | 2800 | 1.45 | 250 | 20 | 1000 | MDS |
| MDS200-18 |
|
|
YFW MDS200-18 | 200 | 1800 | 2240 | 1.45 | 200 | 16 | 1000 | M10 |
| MDS200-16 |
|
|
YFW MDS200-16 | 200 | 1600 | 2240 | 1.45 | 200 | 16 | 1000 | M10 |
| MDS200-12 |
|
|
YFW MDS200-12 | 200 | 1200 | 2240 | 1.45 | 200 | 16 | 1000 | M10 |
| MDS200-18 |
|
|
YFW MDS200-18 | 200 | 1800 | 2240 | 1.55 | 300 | 300 | 1000 | M11 |
| MDS200-16 |
|
|
YFW MDS200-16 | 200 | 1600 | 2240 | 1.55 | 300 | 300 | 1000 | M11 |
| MDS200-12 |
|
|
YFW MDS200-12 | 200 | 1200 | 2240 | 1.55 | 300 | 300 | 1000 | M11 |
| SGBJ3512 |
|
|
YFW SGBJ3512 | 35 | 1200 | 450 | 1.1 | 17.5 | 5 | 1000 | SGBJ |
| SGBJ3510 |
|
|
YFW SGBJ3510 | 35 | 1000 | 450 | 1.1 | 17.5 | 5 | 1000 | SGBJ |
| SGBJ3508 |
|
|
YFW SGBJ3508 | 35 | 800 | 450 | 1.1 | 17.5 | 5 | 1000 | SGBJ |
| SGBJ2516 |
|
|
YFW SGBJ2516 | 25 | 1600 | 350 | 1.18 | 12.5 | 3000 | 1000 | SGBJ |
| SGBJ2514 |
|
|
YFW SGBJ2514 | 25 | 1400 | 350 | 1.18 | 12.5 | 3000 | 1000 | SGBJ |
| SGBJ2512 |
|
|
YFW SGBJ2512 | 25 | 1200 | 350 | 1.18 | 12.5 | 3000 | 1000 | SGBJ |
| SGBJ2510 |
|
|
YFW SGBJ2510 | 25 | 1000 | 350 | 1.18 | 12.5 | 3000 | 1000 | SGBJ |
| SGBJ2508 |
|
|
YFW SGBJ2508 | 25 | 800 | 350 | 1.18 | 12.5 | 3000 | 1000 | SGBJ |
| SGBJ1516 |
|
|
YFW SGBJ1516 | 15 | 1600 | 250 | 1.18 | 7.5 | 3000 | 1000 | SGBJ |
| SGBJ1514 |
|
|
YFW SGBJ1514 | 15 | 1400 | 250 | 1.18 | 7.5 | 3000 | 1000 | SGBJ |
| MDS250-18 |
|
|
YFW MDS250-18 | 250 | 1800 | 2800 | 1.45 | 250 | 20 | 1000 | MDS |
| MT3510W |
|
|
YFW MT3510W | 35 | 1000 | 350 | 1.1 | 350 | 5 | 1000 | MTW |
| MT3512W |
|
|
YFW MT3512W | 35 | 1200 | 350 | 1.1 | 350 | 5 | 1000 | MTW |
| MT3514W |
|
|
YFW MT3514W | 35 | 1400 | 350 | 1.1 | 350 | 5 | 1000 | MTW |
| MT3516W |
|
|
YFW MT3516W | 35 | 1600 | 350 | 1.1 | 350 | 5 | 1000 | MTW |
| SGBJ1508 |
|
|
YFW SGBJ1508 | 15 | 800 | 250 | 1.18 | 7.5 | 3000 | 1000 | SGBJ |
| SGBJ1510 |
|
|
YFW SGBJ1510 | 15 | 1000 | 250 | 1.18 | 7.5 | 3000 | 1000 | SGBJ |
| SGBJ1512 |
|
|
YFW SGBJ1512 | 15 | 1200 | 250 | 1.18 | 7.5 | 3000 | 1000 | SGBJ |
| SGBJ3516 |
|
|
YFW SGBJ3516 | 35 | 1600 | 450 | 1.1 | 17.5 | 5 | 1000 | SGBJ |
| SGBJ5008 |
|
|
YFW SGBJ5008 | 50 | 800 | 500 | 1.1 | 25 | 3000 | 1000 | SGBJ |
| SGBJ5010 |
|
|
YFW SGBJ5010 | 50 | 1000 | 500 | 1.1 | 25 | 3000 | 1000 | SGBJ |
| SGBJ5012 |
|
|
YFW SGBJ5012 | 50 | 1200 | 500 | 1.1 | 25 | 3000 | 1000 | SGBJ |
| SGBJ5014 |
|
|
YFW SGBJ5014 | 50 | 1400 | 500 | 1.1 | 25 | 3000 | 1000 | SGBJ |
| SGBJ5016 |
|
|
YFW SGBJ5016 | 50 | 1600 | 500 | 1.1 | 25 | 3000 | 1000 | SGBJ |
| SKBPC3510 |
|
|
YFW SKBPC3510 | 35 | 1000 | 450 | 1.05 | 35 | 10 | 1000 | SKBPC |
| SKBPC3512 |
|
|
YFW SKBPC3512 | 35 | 1200 | 450 | 1.05 | 35 | 10 | 1000 | SKBPC |
| SKBPC3516 |
|
|
YFW SKBPC3516 | 35 | 1600 | 450 | 1.05 | 35 | 10 | 1000 | SKBPC |
| SKBPC3518 |
|
|
YFW SKBPC3518 | 35 | 1800 | 450 | 1.05 | 35 | 10 | 1000 | SKBPC |
