TSS固态放电管

Type	Datasheet	Circuit	Marking	VDRM	IDRM	VS	IS	VT	IT	Co	IH	Package
				Min.	Max.	Max.	Max.	Max.	Max.	Typ.	Min.
				V	Ua	V	Ma	V	A	Pf	mA
重置全部	/	/	/	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	DO-15 SMA SMB Reset
	/	/	/
TPA62			YFW TPA62	56	2	62	1	82	0.8	150	150	DO-15
TPA68			YFW TPA68	61	2	68	1	90	0.8	150	150	DO-15
TPA100			YFW TPA100	90	2	100	1	133	0.8	100	150	DO-15
TPA120			YFW TPA120	10.8	2	120	1	160	0.8	100	150	DO-15
TPA130			YFW TPA130	11.7	2	130	1	173	0.8	100	150	DO-15
TPA180			YFW TPA180	16.2	2	180	1	240	0.8	100	150	DO-15
TPA200			YFW TPA200	18	2	200	1	267	0.8	100	150	DO-15
TPA220			YFW TPA220	19.8	2	220	1	293	0.8	100	150	DO-15
TPA240			YFW TPA240	21.6	2	240	1	320	0.8	100	150	DO-15
TPA270			YFW TPA270	24.3	2	270	1	360	0.8	100	150	DO-15
P0060TAL			P006AL	6	5	15	800	4	2.2	10	50	SMA
P0080TAL			P008AL	6	5	25	800	4	2.2	15	50	SMA
P0300TAL			P030AL	25	5	40	800	4	2.2	10	50	SMA
P0640TAL			P064AL	58	5	77	800	4	2.2	15	150	SMA
P0720TAL			P072AL	65	5	88	800	4	2.2	10	150	SMA
P0900TAL			P090AL	75	5	98	800	4	2.2	10	150	SMA
P1100TAL			P110AL	90	5	130	800	4	2.2	10	150	SMA
P1300TAL			P130AL	120	5	160	800	4	2.2	10	150	SMA
P1500TAL			P150AL	140	5	180	800	4	2.2	10	150	SMA
P1800TAL			P180AL	170	5	220	800	4	2.2	10	150	SMA
P2300TAL			P230AL	190	5	260	800	4	2.2	10	150	SMA
P2600TAL			P260AL	220	5	300	800	4	2.2	10	150	SMA
P3100TAL			P310AL	275	5	350	800	4	2.2	8	150	SMA
P3500TAL			P350AL	320	5	400	800	4	2.2	8	150	SMA
P4200TAL			P420AL	390	5	500	800	4	2.2	8	0	SMA
P0080SB			YFW P0080SB	6	5	25	800	4	2.2	80	20	SMB
P0300SB			YFW P0300SB	25	5	40	800	4	2.2	100	50	SMB
P0640SB			YFW P0640SB	58	5	77	800	4	2.2	80	100	SMB
P0720SB			YFW P0720SB	65	5	88	800	4	2.2	80	100	SMB
P0900SB			YFW P0900SB	75	5	98	800	4	2.2	75	100	SMB
P1100SB			YFW P1100SB	90	5	130	800	4	2.2	75	100	SMB
P1300SB			YFW P1300SB	120	5	160	800	4	2.2	75	100	SMB
P1500SB			YFW P1500SB	140	5	180	800	4	2.2	70	100	SMB
P1800SB			YFW P1800SB	170	5	220	800	4	2.2	70	100	SMB
P2000SB			YFW P2000SB	180	5	220	800	4	2.2	70	100	SMB
P2300SB			YFW P2300SB	190	5	260	800	4	2.2	65	100	SMB
P2600SB			YFW P2600SB	220	5	300	800	4	2.2	65	100	SMB
P3100SB			YFW P3100SB	275	5	350	800	4	2.2	60	100	SMB
P3500SB			YFW P3500SB	320	5	400	800	4	2.2	60	100	SMB
P4000SB			YFW P4000SB	360	5	460	800	4	2.2	60	100	SMB
P4200SB			YFW P4200SB	390	5	500	800	4	2.2	60	100	SMB
P4500SB			YFW P4500SB	420	5	540	800	4	2.2	60	100	SMB
P5000SB			YFW P5000SB	500	5	600	800	4	2.2	60	100	SMB
P0080SA			YFW P0080SA	6	5	25	800	4	2.2	50	20	SMB
P0220SA			YFW P0220SA	15	5	32	800	4	2.2	50	50	SMB
P0300SA			YFW P0300SA	25	5	40	800	4	2.2	70	50	SMB
P0640SA			YFW P0640SA	58	5	77	800	4	2.2	50	100	SMB
P0720SA			YFW P0720SA	65	5	88	800	4	2.2	50	100	SMB
P0900SA			YFW P0900SA	75	5	98	800	4	2.2	45	100	SMB
P1100SA			YFW P1100SA	90	5	130	800	4	2.2	45	100	SMB
P1300SA			YFW P1300SA	120	5	160	800	4	2.2	45	100	SMB
P1500SA			YFW P1500SA	140	5	180	800	4	2.2	40	100	SMB
P1800SA			YFW P1800SA	170	5	220	800	4	2.2	40	100	SMB
P2000SA			YFW P2000SA	180	5	220	800	4	2.2	40	100	SMB
P2300SA			YFW P2300SA	190	5	260	800	4	2.2	35	100	SMB
P2600SA			YFW P2600SA	220	5	300	800	4	2.2	35	100	SMB
P3100SA			YFW P3100SA	275	5	350	800	4	2.2	30	100	SMB
P3500SA			YFW P3500SA	320	5	400	800	4	2.2	30	100	SMB
P4000SA			YFW P4000SA	360	5	460	800	4	2.2	30	100	SMB
P4500SA			YFW P4500SA	420	5	540	800	4	2.2	30	100	SMB
P5000SA			YFW P5000SA	500	5	600	800	4	2.2	30	100	SMB
P0060TA			P006A	6	5	25	800	4	2.2	50	50	SMA
P0080TA			P008A	6	5	25	800	4	2.2	50	50	SMA
P0300TA			P030A	25	5	40	800	4	2.2	70	50	SMA
P0640TA			P064A	58	5	77	800	4	2.2	50	150	SMA
P0720TA			P072A	65	5	88	800	4	2.2	50	150	SMA
P0900TA			P090A	75	5	98	800	4	2.2	45	150	SMA
P1100TA			P110A	90	5	130	800	4	2.2	45	150	SMA
P1300TA			P130A	120	5	160	800	4	2.2	45	150	SMA
P1500TA			P150A	140	5	180	800	4	2.2	40	150	SMA
P1800TA			P180A	170	5	220	800	4	2.2	40	150	SMA
P2300TA			P230A	190	5	260	800	4	2.2	35	150	SMA
P2600TA			P260A	220	5	300	800	4	2.2	35	150	SMA
P3100TA			P310A	275	5	350	800	4	2.2	30	150	SMA
P3500TA			P350A	320	5	400	800	4	2.2	30	150	SMA
P4200TA			P420A	390	5	500	800	4	2.2	30	0	SMA
P0060SC			P006C	6	5	25	800	4	2.2	105	50	SMB
P0080SC			P008C	6	5	25	800	4	2.2	105	50	SMB
P0300SC			P030C	25	5	40	800	4	2.2	105	50	SMB
P0640SC			P064C	58	5	77	800	4	2.2	95	150	SMB
P0720SC			P072C	65	5	88	800	4	2.2	95	150	SMB
P0900SC			P090C	75	5	98	800	4	2.2	85	150	SMB
P1100SC			P110C	90	5	130	800	4	2.2	85	150	SMB
P1300SC			P130C	120	5	160	800	4	2.2	85	150	SMB
P1500SC			P150C	140	5	180	800	4	2.2	80	150	SMB
P1800SC			P180C	170	5	220	800	4	2.2	80	150	SMB
P2300SC			P230C	190	5	260	800	4	2.2	75	150	SMB
P2600SC			P260C	220	5	300	800	4	2.2	75	150	SMB
P3100SC			P310C	275	5	350	800	4	2.2	65	150	SMB
P3500SC			P350C	320	5	400	800	4	2.2	65	150	SMB
P4200SC			P420C	390	5	500	800	4	2.2	65	0	SMB
