| Type | Datasheet | Circuit | Marking | I(AV) | VRRM | IFSM | VFM | IRM @ VRRM | Trr | Package | |
| @IRM | VFM | I(AV) | TA=25℃ | ||||||||
| A | V | A | V | A | μA | nS | |||||
| 重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | |||||||||
| ES1DW |
|
|
YFW E1D | 1 | 200 | 30 | 0.95 | 1 | 5 | 35 | SOD-123FL |
| ES1GW |
|
|
YFW E1G | 1 | 400 | 30 | 1.25 | 1 | 5 | 35 | SOD-123FL |
| ES1JW |
|
|
YFW E1J | 1 | 600 | 30 | 1.65 | 1 | 5 | 35 | SOD-123FL |
| ES2DW |
|
|
YFW E2D | 2 | 200 | 50 | 0.95 | 2 | 5 | 35 | SOD-123FL |
| ES2GW |
|
|
YFW E2G | 2 | 400 | 50 | 1.25 | 2 | 5 | 35 | SOD-123FL |
| ES2JW |
|
|
YFW E2J | 2 | 600 | 50 | 1.65 | 2 | 5 | 35 | SOD-123FL |
| ES1DF |
|
|
YFW ES1D | 1 | 200 | 30 | 0.95 | 1 | 5 | 35 | SMAF |
| ES1GF |
|
|
YFW ES1G | 1 | 400 | 30 | 1.25 | 1 | 5 | 35 | SMAF |
| ES1JF |
|
|
YFW ES1J | 1 | 600 | 30 | 1.65 | 1 | 5 | 35 | SMAF |
| ES2DF |
|
|
YFW ES2D | 2 | 200 | 50 | 0.95 | 2 | 5 | 35 | SMAF |
| ES2GF |
|
|
YFW ES2G | 2 | 400 | 50 | 1.25 | 2 | 5 | 35 | SMAF |
| ES2JF |
|
|
YFW ES2J | 2 | 600 | 50 | 1.65 | 2 | 5 | 35 | SMAF |
| ES3DF |
|
|
YFW ES3D | 3 | 200 | 100 | 0.95 | 3 | 5 | 35 | SMAF |
| ES3GF |
|
|
YFW ES3G | 3 | 400 | 100 | 1.25 | 3 | 5 | 35 | SMAF |
| ES3JF |
|
|
YFW ES3J | 3 | 600 | 100 | 1.65 | 3 | 5 | 35 | SMAF |
| ES2DBF |
|
|
YFW ES2DB | 2 | 200 | 50 | 0.95 | 2 | 5 | 35 | SMBF |
| ES2GBF |
|
|
YFW ES2GB | 2 | 400 | 50 | 1.25 | 2 | 5 | 35 | SMBF |
| ES2JBF |
|
|
YFW ES2JB | 2 | 600 | 50 | 1.65 | 2 | 5 | 35 | SMBF |
| ES3DBF |
|
|
YFW ES3DB | 3 | 200 | 100 | 0.95 | 3 | 5 | 35 | SMBF |
| ES3JBF |
|
|
YFW ES3JB | 3 | 600 | 100 | 1.65 | 3 | 5 | 35 | SMBF |
| ES5DBF |
|
|
YFW ES5DB | 5 | 200 | 150 | 0.95 | 5 | 10 | 35 | SMBF |
| ES5GBF |
|
|
YFW ES5GB | 5 | 400 | 150 | 1.25 | 5 | 10 | 35 | SMBF |
| ES5JBF |
|
|
YFW ES5JB | 5 | 600 | 150 | 1.65 | 5 | 10 | 35 | SMBF |
| ES1D |
|
|
YFW ES1D | 1 | 200 | 30 | 0.95 | 1 | 5 | 35 | SMA |
| ES1G |
|
|
YFW ES1G | 1 | 400 | 30 | 1.25 | 1 | 5 | 35 | SMA |
| ES1J |
|
|
YFW ES1J | 1 | 600 | 30 | 1.65 | 1 | 5 | 35 | SMA |
| ES2D |
|
|
YFW ES2D | 2 | 200 | 50 | 0.95 | 2 | 5 | 35 | SMA |
| ES2G |
|
|
YFW ES2G | 2 | 400 | 50 | 1.25 | 2 | 5 | 35 | SMA |
| ES2J |
|
|
YFW ES2J | 2 | 600 | 50 | 1.65 | 2 | 5 | 35 | SMA |
| ES3D |
|
|
YFW ES3D | 3 | 200 | 80 | 0.95 | 3 | 5 | 35 | SMA |
| ES3G |
|
|
YFW ES3G | 3 | 400 | 80 | 1.25 | 3 | 5 | 35 | SMA |
| ES3J |
|
|
YFW ES3J | 3 | 600 | 80 | 1.65 | 3 | 5 | 35 | SMA |
| ES2DB |
|
|
YFW ES2D | 2 | 200 | 60 | 0.95 | 2 | 5 | 35 | SMB |
| ES2GB |
|
|
YFW ES2G | 2 | 400 | 60 | 1.25 | 2 | 5 | 35 | SMB |
| ES2JB |
|
|
YFW ES2J | 2 | 600 | 60 | 1.65 | 2 | 5 | 35 | SMB |
| ES3DB |
|
|
YFW ES3D | 3 | 200 | 90 | 0.95 | 3 | 5 | 35 | SMB |
| ES3GB |
|
|
YFW ES3G | 3 | 400 | 90 | 1.25 | 3 | 5 | 35 | SMB |
| ES3JB |
|
|
YFW ES3J | 3 | 600 | 90 | 1.65 | 3 | 5 | 35 | SMB |
| ES5DB |
|
|
YFW ES5D | 5 | 200 | 100 | 0.95 | 5 | 5 | 35 | SMB |
| ES5GB |
|
|
YFW ES5G | 5 | 400 | 100 | 1.25 | 5 | 5 | 35 | SMB |
| ES5JB |
|
|
YFW ES5J | 5 | 600 | 100 | 1.65 | 5 | 5 | 35 | SMB |
| ES3DC |
|
|
YFW ES3D | 3 | 200 | 90 | 0.95 | 3 | 5 | 35 | SMC |
| ES3GC |
|
|
YFW ES3G | 3 | 400 | 90 | 1.25 | 3 | 5 | 35 | SMC |
| ES3JC |
|
|
YFW ES3J | 3 | 600 | 90 | 1.65 | 3 | 5 | 35 | SMC |
| ES5DC |
|
|
YFW ES5D | 5 | 200 | 120 | 0.95 | 5 | 5 | 35 | SMC |
| ES5GC |
|
|
YFW ES5G | 5 | 400 | 120 | 1.25 | 5 | 5 | 35 | SMC |
| ES5JC |
|
|
YFW ES5J | 5 | 600 | 120 | 1.65 | 5 | 5 | 35 | SMC |
| ES8DC |
|
|
YFW ES8D | 8 | 200 | 125 | 0.95 | 8 | 10 | 35 | SMC |
| ES8GC |
|
|
YFW ES8G | 8 | 400 | 125 | 1.25 | 8 | 10 | 35 | SMC |
| ES8JC |
|
|
YFW ES8J | 8 | 600 | 125 | 1.65 | 8 | 10 | 35 | SMC |
| SF302DS |
|
|
YFW SF302DS | 3 | 200 | 130 | 0.95 | 3 | 1 | 35 | TO-252 |
| SF304DS |
|
|
YFW SF304DS | 3 | 400 | 130 | 1.25 | 3 | 1 | 35 | TO-252 |
| SF306DS |
|
|
YFW SF306DS | 3 | 600 | 130 | 1.65 | 3 | 1 | 35 | TO-252 |
| SF502DS |
|
|
YFW SF502DS | 5 | 200 | 150 | 0.95 | 5 | 1 | 35 | TO-252 |
| SF504DS |
|
|
YFW SF504DS | 5 | 400 | 150 | 1.25 | 5 | 1 | 35 | TO-252 |
| SF506DS |
|
|
YFW SF506DS | 5 | 600 | 150 | 1.65 | 5 | 1 | 35 | TO-252 |
| SF802DS |
|
|
YFW SF802DS | 8 | 200 | 160 | 0.95 | 8 | 1 | 35 | TO-252 |
| SF804DS |
|
|
YFW SF804DS | 8 | 400 | 160 | 1.25 | 8 | 1 | 35 | TO-252 |
| SF806DS |
|
|
YFW SF806DS | 8 | 600 | 160 | 1.65 | 8 | 1 | 35 | TO-252 |
| SF1002DS |
|
|
YFW SF1002DS | 10 | 200 | 170 | 0.95 | 10 | 1 | 35 | TO-252 |
| SF1004DS |
|
|
YFW SF1004DS | 10 | 400 | 170 | 1.25 | 10 | 1 | 35 | TO-252 |
| SF1006DS |
|
|
YFW SF1006DS | 10 | 600 | 170 | 1.65 | 10 | 1 | 35 | TO-252 |
| MUR820DC | / | / | YFW MUR820DC | 8 | 200 | 90 | 0.81 | 8 | 0.1 | 35 | TO-263 |
| MUR840DC | / | / | YFW MUR840DC | 8 | 400 | 120 | 1.1 | 8 | 0.1 | 35 | TO-263 |
| MUR860DC | / | / | YFW MUR860DC | 8 | 600 | 110 | 1.1 | 8 | 0.5 | 35 | TO-263 |
| MUR1020DC | / | / | YFW MUR1020DC | 10 | 200 | 160 | 0.81 | 10 | 0.05 | 35 | TO-263 |
| MUR1040DC |
|
|
YFW MUR1040DC | 10 | 400 | 160 | 0.95 | 10 | 0.007 | 35 | TO-263 |
| MUR1060DC |
|
|
YFW MUR1060DC | 10 | 600 | 100 | 1.03 | 10 | 0.05 | 35 | TO-263 |
| MUR1520DC | / | / | YFW MUR1520DC | 15 | 200 | 320 | 0.81 | 15 | 0.1 | 35 | TO-263 |
| MUR1540DC | / | / | YFW MUR1540DC | 15 | 400 | 320 | 0.91 | 15 | 0.1 | 35 | TO-263 |
| MUR1560DC | / | / | YFW MUR1560DC | 15 | 600 | 320 | 1 | 15 | 0.03 | 50 | TO-263 |
| MUR1620DC |
|
|
YFW MUR1620DC | 16 | 200 | 160 | 0.81 | 16 | 0.05 | 35 | TO-263 |
| MUR1640DC | / | / | YFW MUR1640DC | 16 | 400 | 160 | 1.05 | 16 | 0.05 | 35 | TO-263 |
| MUR1660DC | / | / | YFW MUR1660DC | 16 | 600 | 160 | 1.1 | 16 | 0.05 | 35 | TO-263 |
| MUR2020DC | / | / | YFW MUR2020DC | 20 | 200 | 200 | 0.81 | 20 | 0.01 | 35 | TO-263 |
| MUR2040DC | / | / | YFW MUR2040DC | 20 | 400 | 200 | 0.95 | 20 | 0.01 | 35 | TO-263 |
| MUR2060DC | / | / | YFW MUR2060DC | 20 | 600 | 200 | 1.1 | 20 | 0.01 | 35 | TO-263 |
| MUR3020DC | / | / | YFW MUR3020DC | 30 | 200 | 320 | 0.81 | 30 | 0.1 | 35 | TO-263 |
| MUR3040DC | / | / | YFW MUR3040DC | 30 | 400 | 320 | 0.91 | 30 | 0.03 | 35 | TO-263 |
| MUR3060DC | / | / | YFW MUR3060DC | 30 | 600 | 320 | 1.1 | 30 | 0.1 | 35 | TO-263 |
| SF14 |
|
|
YFW SF14 | 1 | 200 | 35 | 0.95 | 1 | 10 | 35 | DO-41 |
| SF16 |
|
|
YFW SF16 | 1 | 400 | 35 | 1.25 | 1 | 10 | 35 | DO-41 |
| SF18 |
|
|
YFW SF18 | 1 | 600 | 35 | 1.7 | 1 | 10 | 35 | DO-41 |
| SF24 |
|
|
YFW SF24 | 2 | 200 | 60 | 0.95 | 2 | 10 | 35 | DO-15 |
| SF26 |
|
|
YFW SF26 | 2 | 400 | 60 | 1.25 | 2 | 10 | 35 | DO-15 |
| SF28 |
|
|
YFW SF28 | 2 | 600 | 60 | 1.7 | 2 | 10 | 35 | DO-15 |
| MUR220 |
|
|
YFW MUR220 | 2 | 200 | 60 | 1 | 2 | 10 | 35 | DO-15 |
| MUR240 |
|
|
YFW MUR240 | 2 | 400 | 60 | 1.3 | 2 | 10 | 50 | DO-15 |
| MUR260 |
|
|
YFW MUR260 | 2 | 600 | 60 | 1.8 | 2 | 10 | 50 | DO-15 |
| SF34 |
|
|
YFW SF34 | 3 | 200 | 150 | 0.95 | 3 | 10 | 35 | DO-27 |
| SF36 |
|
|
YFW SF36 | 3 | 400 | 150 | 1.25 | 3 | 10 | 35 | DO-27 |
| SF38 |
|
|
YFW SF38 | 3 | 600 | 150 | 1.65 | 3 | 10 | 35 | DO-27 |
| MUR420 |
|
|
YFW MUR420 | 4 | 200 | 125 | 0.95 | 4 | 5 | 45 | DO-27 |
| MUR460 |
|
|
YFW MUR460 | 4 | 600 | 125 | 1.25 | 4 | 5 | 50 | DO-27 |
| MUR4100 |
|
|
YFW MUR4100 | 4 | 1000 | 125 | 1.75 | 4 | 5 | 75 | DO-27 |
| MUR420G |
|
|
YFW MUR420G | 4 | 200 | 125 | 0.95 | 4 | 5 | 45 | DO-27 |
| MUR460G |
|
|
YFW MUR460G | 4 | 600 | 125 | 1.25 | 4 | 5 | 50 | DO-27 |
| MUR4100G |
|
|
YFW MUR4100G | 4 | 1000 | 125 | 1.75 | 4 | 5 | 75 | DO-27 |
| SF54 |
|
|
YFW SF54 | 5 | 200 | 200 | 0.95 | 5 | 10 | 35 | DO-27 |
| SF56 |
|
|
YFW SF56 | 5 | 400 | 200 | 1.25 | 5 | 10 | 35 | DO-27 |
| SF58 |
|
|
YFW SF58 | 5 | 600 | 200 | 1.65 | 5 | 10 | 35 | DO-27 |
| SF54G |
|
|
YFW SF54G | 5 | 200 | 200 | 0.95 | 5 | 10 | 35 | DO-27 |
| SF56G |
|
|
YFW SF56G | 5 | 400 | 200 | 1.25 | 5 | 10 | 35 | DO-27 |
| SF58G |
|
|
YFW SF58G | 5 | 600 | 200 | 1.65 | 5 | 10 | 35 | DO-27 |
| SF64 |
|
|
YFW SF64 | 6 | 200 | 300 | 0.95 | 6 | 10 | 35 | DO-27 |
| SF66 |
|
|
YFW SF66 | 6 | 400 | 300 | 1.25 | 6 | 10 | 35 | DO-27 |
| SF68 |
|
|
YFW SF68 | 6 | 600 | 300 | 1.65 | 6 | 10 | 35 | DO-27 |
| SF64G |
|
|
YFW SF64G | 6 | 200 | 300 | 0.95 | 6 | 10 | 35 | DO-27 |
| SF66G |
|
|
YFW SF66G | 6 | 400 | 300 | 1.25 | 6 | 10 | 35 | DO-27 |
| SF68G |
|
|
YFW SF68G | 6 | 600 | 300 | 1.65 | 6 | 10 | 35 | DO-27 |
| SF64 |
|
|
YFW SF64 | 6 | 200 | 300 | 0.95 | 6 | 10 | 35 | R-6 |
| SF66 |
|
|
YFW SF66 | 6 | 400 | 300 | 1.25 | 6 | 10 | 35 | R-6 |
| SF68 |
|
|
YFW SF68 | 6 | 600 | 300 | 1.65 | 6 | 10 | 35 | R-6 |
| SR84E |
|
|
YFW SR84E | 8 | 400 | 300 | 1.1 | 8 | 10 | 30 | DO-27 |
| SRA4E |
|
|
YFW SRA4E | 10 | 400 | 350 | 1.1 | 10 | 10 | 30 | DO-27 |
| MUR540AC | / | / | YFW MUR540AC | 5 | 400 | 90 | 1.05 | 5 | 0.1 | 35 | TO-220AC |
| MUR540FAC | / | / | YFW MUR540FAC | 5 | 400 | 90 | 1.05 | 5 | 0.1 | 35 | TO-220FAC |
| MUR560AC | / | / | YFW MUR560AC | 5 | 600 | 90 | 1.1 | 5 | 0.5 | 35 | TO-220AC |
| MUR560FAC | / | / | YFW MUR560FAC | 5 | 600 | 90 | 1.1 | 5 | 0.5 | 35 | TO-220FAC |
| MUR840AC | / | / | YFW MUR840AC | 8 | 400 | 120 | 1.1 | 8 | 0.1 | 35 | TO-220AC |
| MUR840FAC | / | / | YFW MUR840FAC | 8 | 400 | 120 | 1.1 | 8 | 0.1 | 35 | TO-220FAC |
| MUR860AC | / | / | YFW MUR860AC | 8 | 600 | 120 | 1.1 | 8 | 0.5 | 35 | TO-220AC |
| MUR860FAC | / | / | YFW MUR860FAC | 8 | 600 | 120 | 1.1 | 8 | 0.5 | 35 | TO-220FAC |
| MUR1040AC | / | / | YFW MUR1040AC | 10 | 400 | 160 | 0.95 | 10 | 0.007 | 35 | TO-220AC |
| MUR1040FAC | / | / | YFW MUR1040FAC | 10 | 400 | 160 | 0.95 | 10 | 0.007 | 35 | TO-220FAC |
| MUR1060AC | / | / | YFW MUR1060AC | 10 | 600 | 160 | 1.03 | 10 | 0.05 | 35 | TO-220AC |
| MUR1060FAC | / | / | YFW MUR1060FAC | 10 | 600 | 160 | 1.03 | 10 | 0.05 | 35 | TO-220FAC |
| MUR1540AC | / | / | YFW MUR1540AC | 15 | 400 | 320 | 0.91 | 15 | 0.1 | 35 | TO-220AC |
| MUR1540FAC | / | / | YFW MUR1540FAC | 15 | 400 | 320 | 0.91 | 15 | 0.1 | 35 | TO-220FAC |
| MUR1560AC | / | / | YFW MUR1560AC | 15 | 600 | 320 | 1 | 15 | 0.03 | 50 | TO-220AC |
| MUR1560FAC | / | / | YFW MUR1560FAC | 15 | 600 | 320 | 1 | 15 | 0.03 | 50 | TO-220FAC |
| MUR15120AC | / | / | YFW MUR15120AC | 15 | 1200 | 160 | 1.62 | 15 | 0.1 | 50 | TO-220AC |
| MUR15120FAC | / | / | YFW MUR15120FAC | 15 | 1200 | 160 | 1.62 | 15 | 0.1 | 50 | TO-220FAC |
| MUR2540AC | / | / | YFW MUR2540AC | 25 | 400 | 420 | 1 | 25 | 0.1 | 35 | TO-220AC |
| MUR2540FAC | / | / | YFW MUR2540FAC | 25 | 400 | 420 | 1 | 25 | 0.1 | 35 | TO-220FAC |
| MUR3040AC | / | / | YFW MUR3040AC | 30 | 400 | 480 | 1.2 | 30 | 0.03 | 50 | TO-220AC |
| MUR3040FAC | / | / | YFW MUR3040FAC | 30 | 400 | 480 | 1.2 | 30 | 0.03 | 50 | TO-220FAC |
| MUR1040CT |
|
|
YFW MUR1040CT | 10 | 400 | 90 | 1.15 | 10 | 0.1 | 35 | TO-220AB |
| MUR1040FCT |
|
|
YFW MUR1040FCT | 10 | 400 | 90 | 1.15 | 10 | 0.1 | 35 | TO-220F |
| MUR1060CT |
|
|
YFW MUR1060CT | 10 | 600 | 90 | 1.1 | 10 | 0.5 | 35 | TO-220AB |
| MUR1060FCT |
|
|
YFW MUR1060FCT | 10 | 600 | 90 | 1.1 | 10 | 0.5 | 35 | TO-220F |
| MUR1620CT |
|
|
YFW MUR1620CT | 16 | 200 | 160 | 0.81 | 16 | 0.05 | 35 | TO-220AB |
| MUR1620FCT |
|
|
YFW MUR1620FCT | 16 | 200 | 160 | 0.81 | 16 | 0.05 | 35 | TO-220F |
| MUR1640CT | / | / | YFW MUR1640CT | 16 | 400 | 160 | 1.1 | 16 | 0.1 | 35 | TO-220AB |
| MUR1640FCT | / | / | YFW MUR1640FCT | 16 | 400 | 160 | 1.1 | 16 | 0.1 | 35 | TO-220F |
| MUR1660CT | / | / | YFW MUR1660CT | 16 | 600 | 160 | 1.1 | 16 | 0.05 | 35 | TO-220AB |
| MUR1660FCT | / | / | YFW MUR1660FCT | 16 | 600 | 160 | 1.1 | 16 | 0.05 | 35 | TO-220F |
| MUR2020CT | / | / | YFW MUR2020CT | 20 | 200 | 200 | 0.81 | 20 | 0.1 | 35 | TO-220AB |
| MUR2020FCT | / | / | YFW MUR2020FCT | 20 | 200 | 200 | 0.81 | 20 | 0.1 | 35 | TO-220F |
| MUR2040CT | / | / | YFW MUR2040CT | 20 | 400 | 200 | 0.95 | 20 | 0.01 | 35 | TO-220AB |
| MUR2040FCT | / | / | YFW MUR2040FCT | 20 | 400 | 200 | 0.95 | 20 | 0.01 | 35 | TO-220F |
| MUR2060CT | / | / | YFW MUR2060CT | 20 | 600 | 200 | 1.1 | 20 | 0.05 | 35 | TO-220AB |
| MUR2060FCT | / | / | YFW MUR2060FCT | 20 | 600 | 200 | 1.1 | 20 | 0.05 | 35 | TO-220F |
| MUR3020CT | / | / | YFW MUR3020CT | 30 | 200 | 320 | 0.88 | 30 | 0.1 | 35 | TO-220AB |
| MUR3020FCT | / | / | YFW MUR3020FCT | 30 | 200 | 320 | 0.88 | 30 | 0.1 | 35 | TO-220F |
| MUR3040CT | / | / | YFW MUR3040CT | 30 | 400 | 320 | 0.91 | 30 | 0.1 | 35 | TO-220AB |
| MUR3040FCT | / | / | YFW MUR3040FCT | 30 | 400 | 320 | 0.91 | 30 | 0.1 | 35 | TO-220F |
| MUR3060CT | / | / | YFW MUR3060CT | 30 | 600 | 320 | 1.2 | 30 | 0.1 | 35 | TO-220AB |
| MUR3060FCT | / | / | YFW MUR3060FCT | 30 | 600 | 320 | 1.2 | 30 | 0.1 | 35 | TO-220F |
| MUR3040PT |
|
|
YFW MUR3040PT | 30 | 400 | 320 | 0.91 | 30 | 0.1 | 50 | TO-247 |
| MUR3040PTS |
|
|
YFW MUR3040PTS | 30 | 400 | 320 | 0.91 | 30 | 0.1 | 50 | TO-247S |
| MUR3060PT |
|
|
YFW MUR3060PT | 30 | 600 | 250 | 1 | 30 | 0.03 | 50 | TO-247 |
| MUR3060PTS |
|
|
YFW MUR3060PTS | 30 | 600 | 250 | 1 | 30 | 0.03 | 50 | TO-247S |
| MUR30120PT |
|
|
YFW MUR30120PT | 30 | 1200 | 160 | 1.6 | 30 | 0.1 | 50 | TO-247 |
| MUR30120PTS |
|
|
YFW MUR30120PTS | 30 | 1200 | 160 | 1.6 | 30 | 0.1 | 50 | TO-247S |
| MUR30150PT | / | / | YFW MUR30150PT | 30 | 1500 | 135 | 1.75 | 30 | 0.1 | 50 | TO-247 |
| MUR30150PTS | / | / | YFW MUR30150PTS | 30 | 1500 | 135 | 1.75 | 30 | 0.1 | 50 | TO-247S |
| MUR4020PT |
|
|
YFW MUR4020PT | 40 | 200 | 220 | 0.81 | 40 | 0.02 | 35 | TO-247 |
| MUR4020PTS |
|
|
YFW MUR4020PTS | 40 | 200 | 220 | 0.81 | 40 | 0.02 | 35 | TO-247S |
| MUR4030PT |
|
|
YFW MUR4030PT | 40 | 300 | 430 | 1.05 | 40 | 0.02 | 50 | TO-247 |
| MUR4030PTS |
|
|
YFW MUR4030PTS | 40 | 300 | 430 | 1.05 | 40 | 0.02 | 50 | TO-247S |
| MUR4040PT |
|
|
YFW MUR4040PT | 40 | 400 | 390 | 0.91 | 40 | 0.02 | 50 | TO-247 |
| MUR4040PTS |
|
|
YFW MUR4040PTS | 40 | 400 | 390 | 0.91 | 40 | 0.02 | 50 | TO-247S |
| MUR4060PT |
|
|
YFW MUR4060PT | 40 | 600 | 330 | 1.05 | 40 | 0.1 | 50 | TO-247 |
| MUR4060PTS |
|
|
YFW MUR4060PTS | 40 | 600 | 330 | 1.05 | 40 | 0.1 | 50 | TO-247S |
| MUR40120PT | / | / | YFW MUR40120PT | 40 | 1200 | 180 | 1.6 | 40 | 0.03 | 50 | TO-247 |
| MUR40120PTS | / | / | YFW MUR40120PTS | 40 | 1200 | 180 | 1.6 | 40 | 0.03 | 50 | TO-247S |
| MUR40150PT | / | / | YFW MUR40150PT | 40 | 1500 | 150 | 1.75 | 40 | 0.03 | 50 | TO-247 |
| MUR40150PTS | / | / | YFW MUR40150PTS | 40 | 1500 | 150 | 1.75 | 40 | 0.03 | 50 | TO-247S |
| MUR5020PT | / | / | YFW MUR5020PT | 50 | 200 | 260 | 0.81 | 50 | 0.02 | 35 | TO-247 |
| MUR5020PTS | / | / | YFW MUR5020PTS | 50 | 200 | 260 | 0.81 | 50 | 0.02 | 35 | TO-247S |
| MUR5030PT |
|
|
YFW MUR5030PT | 50 | 300 | 470 | 0.95 | 50 | 0.1 | 50 | TO-247 |
| MUR5030PTS |
|
|
YFW MUR5030PTS | 50 | 300 | 470 | 0.95 | 50 | 0.1 | 50 | TO-247S |
| MUR5040PT |
|
|
YFW MUR5040PT | 50 | 400 | 420 | 0.1 | 50 | 0.1 | 35 | TO-247 |
| MUR5040PTS |
|
|
YFW MUR5040PTS | 50 | 400 | 420 | 0.1 | 50 | 0.1 | 35 | TO-247S |
| MUR5060PT | / | / | YFW MUR5060PT | 50 | 600 | 340 | 1 | 50 | 0.02 | 50 | TO-247 |
| MUR5060PTS | / | / | YFW MUR5060PTS | 50 | 600 | 340 | 1 | 50 | 0.02 | 50 | TO-247S |
| MUR6020PT | / | / | YFW MUR6020PT | 60 | 200 | 500 | 0.81 | 60 | 0.1 | 50 | TO-247 |
| MUR6020PTS | / | / | YFW MUR6020PTS | 60 | 200 | 500 | 0.81 | 60 | 0.1 | 50 | TO-247S |
| MUR6040PT |
|
|
YFW MUR6040PT | 60 | 400 | 480 | 1.05 | 60 | 0.1 | 50 | TO-247 |
| MUR6040PTS |
|
|
YFW MUR6040PTS | 60 | 400 | 480 | 1.05 | 60 | 0.1 | 50 | TO-247S |
| MUR6060PT |
|
|
YFW MUR6060PT | 60 | 600 | 420 | 1.05 | 60 | 0.1 | 50 | TO-247 |
| MUR6060PTS |
|
|
YFW MUR6060PTS | 60 | 600 | 420 | 1.05 | 60 | 0.1 | 50 | TO-247S |
| ES1K |
|
|
YFW ES1K | 1 | 800 | 25 | 3.2 | 1 | 5 | 35 | SMA |
| ES1M |
|
|
YFW ES1M | 1 | 1000 | 25 | 3.2 | 1 | 5 | 35 | SMA |
| ES5ASP | / | / | YFW ES5ASP | 5 | 50 | 100 | 1 | 5 | 5 | 35 | TO-277 |
| ES5BSP | / | / | YFW ES5BSP | 5 | 100 | 100 | 1 | 5 | 5 | 35 | TO-277 |
| ES5CSP | / | / | YFW ES5CSP | 5 | 150 | 100 | 1 | 5 | 5 | 35 | TO-277 |
| ES5DSP | / | / | YFW ES5DSP | 5 | 200 | 100 | 1 | 5 | 5 | 35 | TO-277 |
| ES5FSP | / | / | YFW ES5FSP | 5 | 300 | 100 | 1.3 | 5 | 5 | 35 | TO-277 |
| ES5GSP | / | / | YFW ES5GSP | 5 | 400 | 100 | 1.3 | 5 | 5 | 35 | TO-277 |
| ES5JSP | / | / | YFW ES5JSP | 5 | 600 | 100 | 1.7 | 5 | 5 | 35 | TO-277 |
| SF1008DS |
|
|
YFW SF1008DS | 10 | 800 | 160 | 2.8 | 10 | 1 | 35 | TO-252 |
| MUR60120W | / | / | YFW MUR60120W | 60 | 1200 | 350 | 3.3 | 60 | 15 | 85 | TO-247-2L |
| MUR30120W | / | / | YFW MUR30120W | 30 | 1200 | 300 | 3.5 | 30 | 10 | 60 | TO-247-2L |
| MUR6060W | / | / | YFW MUR6060W | 60 | 600 | 420 | 1.3 | 60 | 1 | 30 | TO-247-2L |
| MUR3060W | / | / | YFW MUR3060W | 30 | 600 | 420 | 1.06 | 30 | 1 | 50 | TO-247-2L |
| MUR3060WS | / | / | YFW MUR3060WS | 30 | 600 | 420 | 1.06 | 30 | 1 | 50 | TO-247S-2L |
| MUR3040SW | / | / | YFW MUR3040SW | 30 | 400 | 30 | 1.5 | 30 | 1 | 40 | TO-247-2L |
| ES1DLWS |
|
|
E1D | 0.5 | 300 | 15 | 1.25 | 0.5 | 5 | 35 | SOD-323 |
| ES1GLWS |
|
|
E1G | 0.5 | 400 | 15 | 1.25 | 0.5 | 5 | 35 | SOD-323 |
| ES1JLWS |
|
|
E1J | 0.5 | 600 | 15 | 1.68 | 0.5 | 5 | 35 | SOD-323 |
| ES6DC |
|
|
YFW ES6DC | 5 | 200 | 150 | 0.95 | 5 | 5 | 35 | SMC |
| ES6GC |
|
|
YFW ES6GC | 5 | 400 | 150 | 1.25 | 5 | 5 | 35 | SMC |
| ES6JC |
|
|
YFW ES6JC | 5 | 600 | 150 | 1.65 | 5 | 5 | 35 | SMC |
| SRA6E |
|
|
YFW SRA6E | 10 | 600 | 220 | 1.55 | 10 | 10 | 30 | DO-27 |
| MUR30120AC | / | / | YFW MUR30120AC | 30 | 1200 | 350 | 3 | 30 | 50 | 60 | TO-220AC |
| MUR20120AC | / | / | YFW MUR20120AC | 20 | 1200 | 230 | 1.79 | 20 | 0.2 | 75 | TO-220AC |
| MUR20120FAC | / | / | YFW MUR20120FAC | 20 | 1200 | 230 | 1.79 | 20 | 0.2 | 75 | TO-220FAC |
| MUR20120FDC | / | / | YFW MUR20120FDC | 20 | 1200 | 230 | 1.79 | 20 | 0.2 | 75 | TO-263 |
| MUR16120CT | / | / | YFW MUR16120CT | 8 | 1200 | 80 | 1.58 | 8 | 0.2 | 50 | TO-220AB |
| MUR16120FCT | / | / | YFW MUR16120FCT | 8 | 1200 | 80 | 1.58 | 8 | 0.2 | 50 | TO-220F |
| MUR16120DC | / | / | YFW MUR16120DC | 8 | 1200 | 80 | 1.58 | 8 | 0.2 | 50 | TO-263 |
| MUR1680CT | / | / | YFW MUR1680CT | 8 | 800 | 80 | 1.3 | 8 | 0.05 | 35 | TO-220AB |
| MUR1680FCT | / | / | YFW MUR1680FCT | 8 | 800 | 80 | 1.3 | 8 | 0.05 | 35 | TO-220F |
| MUR1680DC | / | / | YFW MUR1680DC | 8 | 800 | 80 | 1.3 | 8 | 0.05 | 35 | TO-263 |
| MUR1020CT |
|
|
YFW MUR1020CT | 5 | 200 | 90 | 0.85 | 5 | 0.5 | 35 | TO-220AB |
| MUR1020FCT |
|
|
YFW MUR1020FCT | 5 | 200 | 90 | 0.85 | 5 | 0.5 | 35 | TO-220F |
| MUR1020DC |
|
|
YFW MUR1020DC | 5 | 200 | 90 | 0.85 | 5 | 0.5 | 35 | TO-263 |
| SRA4ES | / | / | YFW SRA4ES | 10 | 400 | 175 | 1.3 | 10 | 10 | / | SMP-6 |
| ES3GBF |
|
|
YFW ES3GBF | 3 | 400 | 100 | 1.25 | 3 | 5 | 35 | SMBF |
| MUR8020PT | / |
|
40 | 200 | 800 | 1.2 | 40 | 10 | 50 | TO-247 | |
| MUR8040PT | / |
|
40 | 400 | 600 | 1.6 | 40 | 10 | 50 | TO-247 | |
| MUR8060PT | / |
|
40 | 600 | 600 | 1.8 | 40 | 10 | 55 | TO-247 | |
| MUR3060FAC | / | / | 30 | 600 | 300 | 1.6 | 30 | 10 | 35 | TO-220FAC | |
| MUR3060AC | / | / | 30 | 600 | 300 | 1.6 | 30 | 10 | 35 | TO-220AC | |
| MUR2020FAC | / | / | 20 | 200 | 250 | 1 | 20 | 10 | 35 | TO-220FAC | |
| MUR2040FAC | / | / | 20 | 400 | 250 | 1.3 | 20 | 10 | 35 | TO-220FAC | |
| MUR2060FAC | / | / | 20 | 600 | 250 | 1.6 | 20 | 10 | 35 | TO-220FAC | |
| MUR2020AC | / | / | 20 | 200 | 250 | 1 | 20 | 10 | 35 | TO-220AC | |
| MUR2040AC | / | / | 20 | 400 | 250 | 1.3 | 20 | 10 | 35 | TO-220AC | |
| MUR2060AC | / | / | 20 | 600 | 250 | 1.6 | 20 | 10 | 35 | TO-220AC | |
| MUR1660FAC | / | / | 16 | 600 | 150 | 1.6 | 16 | 10 | 35 | TO-220FAC | |
| MUR1660AC | / | / | 16 | 600 | 200 | 1.6 | 16 | 10 | 35 | TO-220AC | |
| MUR1640FAC | / | / | 16 | 400 | 150 | 1.3 | 16 | 10 | 35 | TO-220FAC | |
| MUR1620FAC | / | / | 16 | 200 | 150 | 1.05 | 16 | 10 | 35 | TO-220FAC | |
