| Type | Datasheet | Circuit | Technology | VCE | Ic@Tc=100℃ | Vce(sat) | VGE(TH) | Eoff | VF | Package |
| V | A | V | V | mJ | V | |||||
| 重置全部 | / | / |
Reset
OK
|
Reset
OK
|
Reset
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | |||||||||
| YFWG40T120HAP |
|
|
1200 | 80 | 1.9 | 6 | 1.4 | 2 | TO-247 | |
| YFWG06T65AC |
|
|
650 | 6 | 1.7 | 6.2 | 0.1 | 1.6 | TO-220C | |
| YFWG06T65AS |
|
|
650 | 6 | 1.7 | 6.2 | 0.1 | 1.6 | TO-263 | |
| YFWG15T65AC |
|
|
650 | 15 | 1.8 | 5.6 | 0.27 | 1.4 | TO-220C | |
| YFWG15T65AS |
|
|
650 | 15 | 1.8 | 5.6 | 0.27 | 1.4 | TO-263 | |
| YFWG30T65AF |
|
|
650 | 30 | 1.7 | 5.7 | 0.6 | 1.4 | TO-220F | |
| YFWG30T65HAF |
|
|
650 | 30 | 1.69 | 5.3 | 0.77 | 2 | TO-220F | |
| YFW20T65HAP |
|
|
650 | 20 | 1.75 | 5.3 | 0.39 | 1.46 | TO-247 | |
| YFWG15T120AP |
|
|
1200 | 15 | 1.7 | 6.2 | 1 | 2.3 | TO-247 | |
| YFWG30T65HAP |
|
|
650 | 30 | 1.69 | 5.3 | 0.77 | 2 | TO-247 | |
| YFWG30T65LAP |
|
|
650 | 30 | 1.7 | 5.7 | 0.6 | 1.4 | TO-247 | |
| YFWG40T65HAP |
|
|
650 | 40 | 1.7 | 5 | 0.6 | 1.5 | TO-247 | |
| YFWG40T65LAP |
|
|
650 | 40 | 1.65 | 5.3 | 1.16 | 2.2 | TO-247 | |
| YFWG40T65UAP |
|
|
650 | 40 | 1.9 | 5 | 0.5 | 2.4 | TO-247 | |
| YFWG40T120AP |
|
|
1200 | 40 | 1.7 | 5.3 | 2.3 | 1.6 | TO-247 | |
| YFWG40T120UAP |
|
|
1200 | 40 | 1.9 | 6 | 1.4 | 3.1 | TO-247 | |
| YFWG50T65HAP |
|
|
650 | 50 | 1.8 | 5.4 | 1 | 1.8 | TO-247 | |
| YFWG60T65AP |
|
|
650 | 60 | 1.8 | 5 | 1.3 | 1.7 | TO-247 | |
| YFWG60T65LAP |
|
|
650 | 60 | 1.7 | 5.3 | 1.2 | 1.45 | TO-247 | |
| YFWG75T65LAP |
|
|
650 | 75 | 1.6 | 5.3 | 2.33 | 1.68 | TO-247 | |
| YFWG06T65AD |
|
|
650 | 6 | 1.7 | 6.2 | 0.1 | 1.6 | TO-252 | |
| YFWG25T120AP |
|
|
1200 | 25 | 2.3 | 6.1 | 0.9 | 1.6 | TO-247 | |
| YFWG75T65AP |
|
|
650 | 75 | 2.5 | 5 | 2.2 | 1.4 | TO-247 | |
| YFWG15T65AF |
|
|
650 | 15 | 1.9 | 5.6 | 0.27 | 1.2 | TO-220F |
