Type	Datasheet	Circuit	Marking	Polarity	PC	lo	VCC	Gi	Vo(on)	R1	R2	Ft	Package
Type	Datasheet	Circuit	Marking	Polarity	mW	mA	V	Gi	V	(Ω)	(Ω)	MHz	Package
重置全部	/	/	/	NPN NPN+NPN NPN+PNP PNP Reset	Reset OK	Reset OK	Reset OK	Reset OK	Reset OK	0 1 10 100 15.4 2.2 22 3.29 32.9 4.7 47 61.1 7 Reset	0 0.047 0.213 1 1.2 10 100 13 2.1 2.2 21 22 28.6 4.5 4.7 47 6.11 61.1 Reset	Reset OK	SOT-23 SOT-323 SOT-363 SOT-523 SOT-723 SOT23-3L TO-126 Reset
	/	/	/
BD681			BD681	NPN	40000	400	100	750	2.5	0	0	250	TO-126
BD680A			BD680A	PNP	40000	400	-80	750	2.5	0	0	250	TO-126
BD680			BD680	PNP	40000	400	-80	750	2.5	0	0	250	TO-126
BD679A			BD679A	NPN	40000	400	80	750	2.5	0	0	250	TO-126
BD679			BD679	NPN	40000	400	80	750	2.5	0	0	250	TO-126
BD678A			BD678A	PNP	40000	400	-60	750	2.5	0	0	250	TO-126
BD678			BD678	PNP	40000	400	-60	750	2.5	0	0	250	TO-126
BD677A			BD677A	NPN	40000	400	60	750	2.5	0	0	250	TO-126
DTC124ECA			DTC124ECA	NPN	200	30	50	56	0.3	22	22	250	SOT-23
DTC144ECA			DTC144ECA	NPN	200	100	50	68	0.3	47	47	250	SOT-23
DTC115ECA			DTC115ECA	NPN	200	20	50	82	0.3	100	100	250	SOT-23
DTD113Z			G21	NPN	200	7.2	50	82	0.3	1	10	200	SOT-23
KRC101S			NA	NPN	200	100	50	30	0.3	4.7	4.7	200	SOT-23
KRC102S			NB	NPN	200	100	50	50	0.3	10	10	200	SOT-23
KRC103S			NC	NPN	200	100	50	70	0.3	22	22	200	SOT-23
KRC104S			ND	NPN	200	100	50	80	0.3	47	47	200	SOT-23
KRC105S			NF	NPN	200	100	50	80	0.3	2.2	47	200	SOT-23
KRC106S			NE	NPN	200	100	50	80	0.3	4.7	47	200	SOT-23
KRC107S			NH	NPN	200	100	50	80	0.3	10	47	200	SOT-23
KRC108S			NI	NPN	200	100	50	80	0.3	22	47	200	SOT-23
KRC109S			NJ	NPN	200	100	50	70	0.3	47	22	200	SOT-23
MMBTRC101SS			NA	NPN	200	100	50	30	0.3	4.7	4.7	200	SOT-23
MMBTRC102SS			NB	NPN	200	100	50	50	0.3	10	10	200	SOT-23
MMBTRC103SS			NC	NPN	200	100	50	70	0.3	22	22	200	SOT-23
MMBTRC104SS			ND	NPN	200	100	50	80	0.3	47	47	200	SOT-23
MMBTRC105SS			NF	NPN	200	100	50	80	0.3	2.2	47	200	SOT-23
MMBTRC106SS			NE	NPN	200	100	50	80	0.3	4.7	47	200	SOT-23
MMBTRC241SS			NQ	NPN	200	300	50	33	0.3	1	1	200	SOT-23
MMBTRC242SS			YP	NPN	200	300	50	39	0.3	2.2	2.2	200	SOT-23
MMBTRC243SS			HP	NPN	200	300	50	47	0.3	4.7	4.7	200	SOT-23
MMBTRC244SS			HN	NPN	200	300	50	56	0.3	10	10	200	SOT-23
MMBTRC245SS			NU	NPN	200	300	50	56	0.3	1	10	200	SOT-23
MMBTRC246SS			NV	NPN	200	300	50	56	0.3	2.2	10	200	SOT-23
MMUN2111			A6A	PNP	200	-100	-50	35	-0.2	10	10	200	SOT-23
MMUN2112			A6B	PNP	200	-100	-50	60	-0.2	22	22	200	SOT-23
MMUN2113			A6C	PNP	200	-100	-50	80	-0.2	47	47	200	SOT-23
MMUN2114			A6D	PNP	200	-100	-50	80	-0.2	10	47	200	SOT-23
MMUN2115			A6E	PNP	200	-100	-50	160	-0.2	10	0	200	SOT-23
MMUN2116			A6F	PNP	200	-100	-50	160	-0.2	4.7	0	200	SOT-23
MMUN2130			A6G	PNP	200	-100	-50	3	-0.2	1	1	200	SOT-23
MMUN2131			A6H	PNP	200	-100	-50	8	-0.2	2.2	2.2	200	SOT-23
MMUN2132			A6J	PNP	200	-100	-50	15	-0.2	4.7	4.7	200	SOT-23
MMUN2133			A6K	PNP	200	-100	-50	80	-0.2	4.7	47	200	SOT-23
MMUN2134			A6L	PNP	200	-100	-50	80	-0.2	22	47	200	SOT-23
MMUN2211			MMUN2211	NPN	200	100	50	35	0.2	10	10	200	SOT-23
MMUN2212			MMUN2212	NPN	200	100	50	60	0.2	22	22	200	SOT-23
MMUN2213			MMUN2213	NPN	200	100	50	80	0.2	47	47	200	SOT-23
MMUN2214			MMUN2214	NPN	200	100	50	80	0.2	10	47	200	SOT-23
MMUN2215			MMUN2215	NPN	200	100	50	160	0.2	10	0	200	SOT-23
MMUN2216			MMUN2216	NPN	200	100	50	160	0.2	4.7	0	200	SOT-23
MMUN2230			MMUN2230	NPN	200	100	50	3	0.2	1	1	200	SOT-23
MMUN2231			MMUN2231	NPN	200	100	50	8	0.2	2.2	2.2	200	SOT-23
MMUN2232			MMUN2232	NPN	200	100	50	15	0.2	4.7	4.7	200	SOT-23
MMUN2233			MMUN2233	NPN	200	100	50	80	0.2	4.7	47	200	SOT-23
MMUN2234			MMUN2234	NPN	200	100	50	80	0.2	22	47	200	SOT-23
MMUN2235			MMUN2235	NPN	200	100	50	80	0.2	2.2	47	200	SOT-23
MMUN2238			MMUN2238	NPN	200	100	50	160	0.2	2.2	0	200	SOT-23
MMUN2241			MMUN2241	NPN	200	100	50	160	0.2	100	0	200	SOT-23
MMDTX144DW			6H	NPN+PNP	200	100	50	80	1.8	10	0.213	200	SOT-363
MMDTX144DW			6H	NPN+PNP	200	-100	-50	80	-1.8	10	0.213	200	SOT-363
MMDTX237DW			D3	NPN+PNP	250	100	50	70	1.1	2.2	0.047	170	SOT-363
MMDTX237DW			D3	NPN+PNP	250	-100	-50	70	-1.1	2.2	0.047	170	SOT-363
MMDTX241DW			D2	NPN+PNP	200	100	50	70	3	22	1	200	SOT-363
MMDTX241DW			D2	NPN+PNP	200	-100	-50	70	-3	22	1	200	SOT-363
MMDTX441DW			D1	NPN+PNP	200	100	50	80	3	47	1	200	SOT-363
MMDTX441DW			D1	NPN+PNP	200	-100	-50	80	-3	47	1	200	SOT-363
MMUN5111DW			0A	PNP	200	-100	-50	60	-4.9	10	10	200	SOT-363
MMUN5112DW			0B	PNP	200	-100	-50	100	-4.9	22	22	200	SOT-363
MMUN5113DW			0C	PNP	200	-100	-50	140	-4.9	47	47	200	SOT-363
MMUN5114DW			0D	PNP	200	-100	-50	140	-4.9	10	47	200	SOT-363
MMUN5115DW			0E	PNP	200	-100	-50	250	-4.9	10	0	200	SOT-363
MMUN5116DW			0F	PNP	200	-100	-50	250	-4.9	4.7	0	200	SOT-363
MMUN5130DW			0G	PNP	200	-100	-50	5	-4.9	1	1	200	SOT-363
MMUN5131DW			0H	PNP	200	-100	-50	15	-4.9	2.2	2.2	200	SOT-363
MMUN5132DW			0J	PNP	200	-100	-50	27	-4.9	4.7	4.7	200	SOT-363
MMUN5133DW			0K	PNP	200	-100	-50	140	-4.9	4.7	4.7	200	SOT-363
MMUN5134DW			0L	PNP	200	-100	-50	130	-4.9	22	4.7	200	SOT-363
MMUN5135DW			0M	PNP	200	-100	-50	140	-4.9	2.2	4.7	200	SOT-363
MMUN5211DW			7A	NPN	250	100	50	35	4.9	10	10	200	SOT-363
MMUN5212DW			7B	NPN	250	100	50	60	4.9	22	22	200	SOT-363
MMUN5213DW			7C	NPN	250	100	50	80	4.9	47	47	200	SOT-363
MMUN5214DW			7D	NPN	250	100	50	80	4.9	10	47	200	SOT-363
MMUN5215DW			7E	NPN	250	100	50	160	4.9	10	0	200	SOT-363
MMUN5216DW			7F	NPN	250	100	50	160	4.9	4.7	0	200	SOT-363
MMUN5230DW			7G	NPN	250	100	50	3	4.9	1	1	200	SOT-363
MMUN5231DW			7H	NPN	250	100	50	8	4.9	2.2	2.2	200	SOT-363
MMUN5232DW			7J	NPN	250	100	50	15	4.9	4.7	4.7	200	SOT-363
MMUN5233DW			7K	NPN	250	100	50	80	4.9	4.7	4.7	200	SOT-363
MMUN5234DW			7L	NPN	250	100	50	80	4.9	22	47	200	SOT-363
MMUN5235DW			7M	NPN	250	100	50	80	4.9	2.2	47	200	SOT-363
MMUN5238DW			7Q	NPN	250	100	50	160	4.9	2.2	0	200	SOT-363
MMUN5241DW			7T	NPN	250	100	50	160	4.9	100	0	200	SOT-363
MMUN5311DW			11	NPN+PNP	250	100	50	60	4.9	10	10	200	SOT-363
MMUN5312DW			12	NPN+PNP	250	100	50	100	4.9	22	22	200	SOT-363
MMUN5313DW			13	NPN+PNP	250	100	50	140	4.9	47	47	200	SOT-363
MMUN5314DW			14	NPN+PNP	250	100	50	140	4.9	10	47	200	SOT-363
MMUN5315DW			15	NPN+PNP	250	100	50	350	4.9	10	0	200	SOT-363
MMUN5316DW			16	NPN+PNP	250	100	50	350	4.9	4.7	0	200	SOT-363
MMUN5330DW			30	NPN+PNP	250	100	50	5	4.9	1	1	200	SOT-363
MMUN5331DW			31	NPN+PNP	250	100	50	15	4.9	2.2	2.2	200	SOT-363
MMUN5332DW			32	NPN+PNP	250	100	50	30	4.9	4.7	4.7	200	SOT-363
MMUN5333DW			33	NPN+PNP	250	100	50	200	4.9	4.7	47	200	SOT-363
MMUN5334DW			34	NPN+PNP	250	100	50	150	4.9	22	47	200	SOT-363
MMUN5335DW			35	NPN+PNP	250	100	50	140	4.9	2.2	47	200	SOT-363
UMH2N			H2	NPN+NPN	150	100	50	68	0.3	61.1	1.2	250	SOT-363
DTA113ZE			E11	PNP	150	-100	-50	33	-0.3	1	10	250	SOT-523
DTA113ZUA			E11	PNP	200	-100	-50	33	-0.3	1	10	250	SOT-323
DTA113ZKA			E11	PNP	200	-100	-50	33	-0.3	1	10	250	SOT23-3L
DTA113ZCA			E11	PNP	200	-100	-50	33	-0.3	1	10	250	SOT-23
DTA114EE			14	PNP	150	-100	-50	30	-0.3	10	1	250	SOT-523
DTA114EUA			14	PNP	200	-100	-50	30	-0.3	10	1	250	SOT-323
DTA11EKA			14	PNP	200	-100	-50	30	-0.3	10	1	250	SOT23-3L
DTA114ECA			14	PNP	200	-100	-50	30	-0.3	10	1	250	SOT-23
DTA114YE			54	PNP	150	-70	-50	68	-0.3	10	4.7	250	SOT-523
DTA114YUA			54	PNP	200	-70	-50	68	-0.3	10	4.7	250	SOT-323
DTA114YKA			54	PNP	200	-70	-50	68	-0.3	10	4.7	250	SOT23-3L
DTA114YCA			54	PNP	200	-70	-50	68	-0.3	10	4.7	250	SOT-23
DTA123JE			E32	PNP	150	-100	-50	80	-0.3	2.2	21	250	SOT-523
DTA123JUA			E32	PNP	200	-100	-50	80	-0.3	2.2	21	250	SOT-323
DTA123JKA			E32	PNP	200	-100	-50	80	-0.3	2.2	21	250	SOT23-3L
DTA123JCA			E32	PNP	200	-100	-50	80	-0.3	2.2	21	250	SOT-23
DTA143EE			13	PNP	150	-100	-50	30	-0.3	4.7	1	250	SOT-523
DTA143EUA			13	PNP	200	-100	-50	30	-0.3	4.7	1	250	SOT-323
DTA143EKA			13	PNP	200	-100	-50	30	-0.3	4.7	1	250	SOT23-3L
DTA143ECA			13	PNP	200	-100	-50	30	-0.3	4.7	1	250	SOT-23
DTA143ZE			E13	PNP	150	-100	-50	80	-0.3	4.7	10	250	SOT-523
DTA143ZUA			113	PNP	200	-100	-50	80	-0.3	4.7	10	250	SOT-323
DTA143ZKA			E13	PNP	200	-100	-50	80	-0.3	4.7	10	250	SOT23-3L
DTA143ZCA			E13	PNP	200	-100	-50	80	-0.3	4.7	10	250	SOT-23
DTA144EM			16	PNP	100	-100	-50	68	-0.3	47	1	250	SOT-723
DTA144EE			16	PNP	150	-100	-50	68	-0.3	47	1	250	SOT-523
DTA144EUA			16	PNP	200	-100	-50	68	-0.3	47	1	250	SOT-323
DTA144EKA			16	PNP	200	-100	-50	68	-0.3	47	1	250	SOT23-3L
DTA144ECA			16	PNP	200	-100	-50	68	-0.3	47	1	250	SOT-23
DTC114EE			24	NPN	150	50	50	30	0.3	7	13	250	SOT-523
DTC124EE			25	NPN	150	30	50	56	0.3	15.4	28.6	250	SOT-523
DTC143EE			23	NPN	150	100	50	20	0.3	3.29	6.11	250	SOT-523
DTC144EE			26	NPN	150	30	50	68	0.3	32.9	61.1	250	SOT-523
DTC114EE			24	NPN	150	50	50	30	0.3	10	1	250	SOT-523
DTC114EUA			24	NPN	200	50	50	30	0.3	10	1	250	SOT-323
DTC114EKA			24	NPN	200	50	50	30	0.3	10	1	250	SOT23-3L
DTC114ECA			24	NPN	200	50	50	30	0.3	10	1	250	SOT-23
DTC123EE			22	NPN	150	100	50	20	0.3	2.2	1	250	SOT-523
DTC123EUA			22	NPN	200	100	50	20	0.3	2.2	1	250	SOT-323
DTC123EKA			22	NPN	200	100	50	20	0.3	2.2	1	250	SOT23-3L
DTC123ECA			22	NPN	200	100	50	20	0.3	2.2	1	250	SOT-23
DTC123JE			E42	NPN	150	100	50	80	0.3	2.2	21	250	SOT-523
DTC123JUA			E42	NPN	200	100	50	80	0.3	2.2	21	250	SOT-323
DTC123JKA			E42	NPN	200	100	50	80	0.3	2.2	21	250	SOT23-3L
DTC123JCA			E42	NPN	200	100	50	80	0.3	2.2	21	250	SOT-23
DTC123YE			62	NPN	150	100	50	33	0.3	2.2	4.5	250	SOT-523
DTC123YUA			62	NPN	200	100	50	33	0.3	2.2	4.5	250	SOT-323
DTC123YCA			62	NPN	200	100	50	33	0.3	2.2	4.5	250	SOT23-3L
DTC12ЗYKA			62	NPN	200	100	50	33	0.3	2.2	4.5	250	SOT-23
DTC143EE			23	NPN	150	100	50	20	0.3	4.7	1	250	SOT-523
DTC143EUA			23	NPN	200	100	50	20	0.3	4.7	1	250	SOT-323
DTC143EKA			23	NPN	200	100	50	20	0.3	4.7	1	250	SOT23-3L
DTC143ECA			23	NPN	200	100	50	20	0.3	4.7	1	250	SOT-23
DTC143XE			43	NPN	150	100	50	30	0.3	4.7	2.1	250	SOT-523
DTC143XUA			43	NPN	200	100	50	30	0.3	4.7	2.1	250	SOT-323
DTC143XKA			43	NPN	200	100	50	30	0.3	4.7	2.1	250	SOT23-3L
DTC143XCA			43	NPN	200	100	50	30	0.3	4.7	2.1	250	SOT-23
DTC143ZE	/	/	E23	NPN	150	100	50	80	1.3	4.7	10	250	SOT-523
DTC144EE			26	NPN	150	30	50	68	0.3	47	1	250	SOT-523
DTC144EUA			26	NPN	200	30	50	68	0.3	47	1	250	SOT-323
DTC144EKA			26	NPN	200	30	50	68	0.3	47	1	250	SOT23-3L
DTC144ECA			26	NPN	200	30	50	68	0.3	47	1	250	SOT-23
DTC144EM			26	NPN	100	30	50	68	0.3	47	1	250	SOT-723
BD675			BD675	NPN	40000	400	45	750	2.5	0	0	250	TO-126
BD675A			BD675A	NPN	40000	400	45	750	2.5	0	0	250	TO-126
BD676			BD676	PNP	40000	400	-45	750	2.5	0	0	250	TO-126
BD676A			BD676A	PNP	40000	400	-45	750	2.5	0	0	250	TO-126
BD677			BD677	NPN	40000	400	60	750	2.5	0	0	250	TO-126
DTC114ECA			DTC114ECA	NPN	200	50	50	30	0.3	10	10	250	SOT-23
DTC143ECA			DTC143ECA	NPN	200	100	50	20	0.3	4.7	4.7	250	SOT-23
BCR135			WJ	NPN	200	100	6	2	1.4	10	21	150	SOT-23
BCR533			XC	NPN	215	500	10	2	1.4	10	1	100	SOT-23
DTC123ECA			DTC123ECA	NPN	200	100	50	20	0.3	2.2	2.2	250	SOT-23
BD682			BD682	PNP	40000	400	-100	750	2.5	0	0	250	TO-126
