Type | Datasheet | Circuit | Marking | I(AV) | VRRM | IFSM | VFM | IRM @ VRRM | Trr | Package | |
@IRM | VFM | I(AV) | TA=25℃ | ||||||||
A | V | A | V | A | μA | nS | |||||
重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
/ | / | / | |||||||||
MB6F-12 | / | / | 1.2 | 600 | 40 | 1.1 | 1.2 | 5 | 1000 | MBF | |
MB10F-10 | / | / | 1 | 1000 | 35 | 1.1 | 1 | 5 | 1000 | MBF | |
MB8F-10 | / | / | 1 | 800 | 35 | 1.1 | 1 | 5 | 1000 | MBF | |
ABS6-12 | / | / | 1.2 | 600 | 50 | 1.1 | 1.2 | 5 | 1000 | ABS | |
ABS8-12 | / | / | 1.2 | 800 | 50 | 1.1 | 1.2 | 5 | 1000 | ABS | |
MB8F-12 | / | / | 1.2 | 800 | 40 | 1.1 | 1.2 | 5 | 1000 | MBF | |
MB10F-12 | / | / | 1.2 | 1000 | 40 | 1.1 | 1.2 | 5 | 1000 | MBF | |
MB6S | 0.8 | 600 | 30 | 1.1 | 0.8 | 5 | 1000 | MBS | |||
MB8S | 0.8 | 800 | 30 | 1.1 | 0.8 | 5 | 1000 | MBS | |||
UM6B | B5 | 0.8 | 600 | 25 | 1.1 | 0.8 | 3 | 1000 | UMB | ||
UM8B | B6 | 0.8 | 800 | 25 | 1.1 | 0.8 | 3 | 1000 | UMB | ||
UM10B | B7 | 0.8 | 1000 | 25 | 1.1 | 0.8 | 3 | 1000 | UMB | ||
UM6B-10 | / | / | UM6B | 1 | 600 | 35 | 1 | 1 | 3 | 1000 | UMB |
UM8B-10 | / | / | UM8B | 1 | 800 | 35 | 1 | 1 | 3 | 1000 | UMB |
UM10B-10 | / | / | UM10B | 1 | 1000 | 35 | 1 | 1 | 3 | 1000 | UMB |
MB6F | 0.8 | 600 | 30 | 1.1 | 1 | 5 | 1000 | MBF | |||
MB8F | 0.8 | 800 | 30 | 1.1 | 1 | 5 | 1000 | MBF | |||
MB10F | 0.8 | 1000 | 30 | 1.1 | 1 | 5 | 1000 | MBF | |||
MB6F-10 | / | / | 1 | 600 | 35 | 1.1 | 1 | 5 | 1000 | MBF | |
MB8S-10 | / | / | 1 | 800 | 35 | 1.1 | 1 | 5 | 1000 | MBS | |
MB10S-10 | / | / | 1 | 1000 | 35 | 1.1 | 1 | 5 | 1000 | MBS | |
MB6S-12 | / | / | 1.2 | 600 | 40 | 1.1 | 1.2 | 5 | 1000 | MBS | |
MB8S-12 | / | / | 1.2 | 800 | 40 | 1.1 | 1.2 | 5 | 1000 | MBS | |
MB10S-12 | / | / | 1.2 | 1000 | 40 | 1.1 | 1.2 | 5 | 1000 | MBS | |
ABS6 | 1 | 600 | 35 | 1.1 | 1 | 5 | 1000 | ABS | |||
ABS8 | 1 | 800 | 35 | 1.1 | 1 | 5 | 1000 | ABS | |||
ABS10 | 1 | 1000 | 35 | 1.1 | 1 | 5 | 1000 | ABS | |||
DB155S | 1.5 | 600 | 55 | 1.1 | 1.5 | 5 | 1000 | DB-S | |||
DB156S | 1.5 | 800 | 55 | 1.1 | 1.5 | 5 | 1000 | DB-S | |||
DB157S | 1.5 | 1000 | 55 | 1.1 | 1.5 | 5 | 1000 | DB-S | |||
DB205S | 2 | 600 | 60 | 1.1 | 2 | 5 | 1000 | DB-S | |||
MB10S | 0.8 | 1000 | 30 | 1.1 | 0.8 | 5 | 1000 | MBS | |||
MB6S-10 | / | / | 1 | 600 | 35 | 1.1 | 1 | 5 | 1000 | MBS | |
DB307S | 3 | 1000 | 80 | 1.15 | 3 | 5 | 1000 | DB-S | |||
MSB20J | / | / | 2 | 600 | 60 | 1.1 | 2 | 5 | 1000 | UMSB | |
MSB20K | / | / | 2 | 800 | 60 | 1.1 | 2 | 5 | 1000 | UMSB | |
MSB20M | / | / | 2 | 1000 | 60 | 1.1 | 2 | 5 | 1000 | UMSB | |
MSB25J | / | / | 2.5 | 600 | 70 | 1.1 | 2.5 | 5 | 1000 | UMSB | |
MSB25K | / | / | 2.5 | 800 | 70 | 1.1 | 2.5 | 5 | 1000 | UMSB | |
MSB25M | / | / | 2.5 | 1000 | 70 | 1.1 | 2.5 | 5 | 1000 | UMSB | |
MSB30J | 3 | 600 | 80 | 1.1 | 3 | 5 | 1000 | UMSB | |||
MSB30K | 3 | 800 | 80 | 1.1 | 3 | 5 | 1000 | UMSB | |||
ABS10-12 | / | / | 1.2 | 1000 | 50 | 1.1 | 1.2 | 5 | 1000 | ABS | |
ABS206 | 2 | 600 | 60 | 1 | 2 | 5 | 1000 | ABS | |||
ABS208 | 2 | 800 | 60 | 1 | 2 | 5 | 1000 | ABS | |||
ABS210 | 2 | 1000 | 60 | 1 | 2 | 5 | 1000 | ABS | |||
DB105S | 1 | 600 | 50 | 1.1 | 1 | 5 | 1000 | DB-S | |||
DB106S | 1 | 800 | 50 | 1.1 | 1 | 5 | 1000 | DB-S | |||
DB107S | 1 | 1000 | 50 | 1.1 | 1 | 5 | 1000 | DB-S | |||
TT606F | 6 | 600 | 200 | 0.83 | 6 | 5 | 1000 | TTF | |||
TT608F | 6 | 800 | 200 | 0.83 | 6 | 5 | 1000 | TTF | |||
TT610F | 6 | 1000 | 200 | 0.83 | 6 | 5 | 1000 | TTF | |||
DB206S | 2 | 800 | 60 | 1.1 | 2 | 5 | 1000 | DB-S | |||
DB207S | 2 | 1000 | 60 | 1.1 | 2 | 5 | 1000 | DB-S | |||
DB305S | 3 | 600 | 80 | 1.15 | 3 | 5 | 1000 | DB-S | |||
DB306S | 3 | 800 | 80 | 1.15 | 3 | 5 | 1000 | DB-S | |||
DB106 | 1 | 800 | 50 | 1.1 | 1 | 5 | 1000 | DB-1 | |||
DB105 | 1 | 600 | 50 | 1.1 | 1 | 5 | 1000 | DB-1 | |||
DB107 | 1 | 1000 | 50 | 1.1 | 1 | 5 | 1000 | DB-1 | |||
DB155 | 1.5 | 600 | 55 | 1.1 | 1.5 | 5 | 1000 | DB-1 | |||
DB156 | 1.5 | 800 | 55 | 1.1 | 1.5 | 5 | 1000 | DB-1 | |||
DB157 | 1.5 | 1000 | 55 | 1.1 | 1.5 | 5 | 1000 | DB-1 | |||
MSB30M | 3 | 1000 | 80 | 1.1 | 3 | 5 | 1000 | UMSB | |||
MSB35K | / | / | 3.5 | 800 | 95 | 1.1 | 3.5 | 5 | 1000 | UMSB | |
MSB35J | / | / | 3.5 | 600 | 95 | 1.1 | 3.5 | 5 | 1000 | UMSB | |
MSB35M | / | / | 3.5 | 1000 | 95 | 1.1 | 3.5 | 5 | 1000 | UMSB | |
MSB40J | 4 | 600 | 95 | 1.1 | 4 | 5 | 1000 | UMSB | |||
MSB40K | 4 | 800 | 95 | 1.1 | 4 | 5 | 1000 | UMSB | |||
MSB40M | 4 | 1000 | 95 | 1.1 | 4 | 5 | 1000 | UMSB | |||
TT506F | 5 | 600 | 180 | 0.83 | 5 | 5 | 1000 | TTF | |||
TT508F | 5 | 800 | 180 | 0.83 | 5 | 5 | 1000 | TTF | |||
TT510F | 5 | 1000 | 180 | 0.83 | 5 | 5 | 1000 | TTF | |||
GBU410 | 4 | 1000 | 135 | 1 | 4 | 5 | 1000 | GBU | |||
GBU606 | 6 | 600 | 175 | 1 | 6 | 5 | 1000 | GBU | |||
GBU608 | 6 | 800 | 175 | 1 | 6 | 5 | 1000 | GBU | |||
TT806F | 8 | 600 | 350 | 0.83 | 8 | 5 | 1000 | TTF | |||
TT808F | 8 | 800 | 350 | 0.83 | 8 | 5 | 1000 | TTF | |||
TT810F | 8 | 1000 | 350 | 0.83 | 8 | 5 | 1000 | TTF | |||
MB6M | 0.8 | 600 | 30 | 1 | 0.8 | 5 | 1000 | MBM | |||
MB8M | 0.8 | 800 | 30 | 1 | 0.8 | 5 | 1000 | MBM | |||
MB10M | 0.8 | 1000 | 30 | 1 | 0.8 | 5 | 1000 | MBM | |||
GBJ606 | 6 | 600 | 150 | 1 | 6 | 5 | 1000 | GBJ | |||
GBJ608 | 6 | 800 | 150 | 1 | 6 | 5 | 1000 | GBJ | |||
GBJ610 | 6 | 1000 | 150 | 1 | 6 | 5 | 1000 | GBJ | |||
GBJ806 | 8 | 600 | 175 | 1 | 8 | 5 | 1000 | GBJ | |||
GBJ808 | 8 | 800 | 175 | 1 | 8 | 5 | 1000 | GBJ | |||
GBU610 | 6 | 1000 | 175 | 1 | 6 | 5 | 1000 | GBU | |||
GBU806 | 8 | 600 | 200 | 1 | 8 | 5 | 1000 | GBU | |||
GBU808 | 8 | 800 | 200 | 1 | 8 | 5 | 1000 | GBU | |||
GBU810 | 8 | 1000 | 200 | 1 | 8 | 5 | 1000 | GBU | |||
GBU1006 | 10 | 600 | 220 | 1 | 10 | 5 | 1000 | GBU | |||
GBU1008 | 10 | 800 | 220 | 1 | 10 | 5 | 1000 | GBU | |||
GBU1010 | 10 | 1000 | 220 | 1 | 10 | 5 | 1000 | GBU | |||
GBU408 | 4 | 800 | 135 | 1 | 4 | 5 | 1000 | GBU | |||
GBU406 | 4 | 600 | 135 | 1 | 4 | 5 | 1000 | GBU | |||
KBP410 | 4 | 1000 | 150 | 1.1 | 4 | 5 | 1000 | KBP | |||
KBP408 | 4 | 800 | 150 | 1.1 | 4 | 5 | 1000 | KBP | |||
KBP406 | 4 | 600 | 150 | 1.1 | 4 | 5 | 1000 | KBP | |||
KBP310 | 3 | 1000 | 110 | 1.1 | 3 | 5 | 1000 | KBP | |||
KBP308 | 3 | 800 | 110 | 1.1 | 3 | 5 | 1000 | KBP | |||
DB205 | 2 | 600 | 60 | 1.1 | 2 | 5 | 1000 | DB-1 | |||
DB206 | 2 | 800 | 60 | 1.1 | 2 | 5 | 1000 | DB-1 | |||
DB207 | 2 | 1000 | 60 | 1.1 | 2 | 5 | 1000 | DB-1 | |||
KBP206 | 2 | 600 | 80 | 1.1 | 2 | 5 | 1000 | KBP | |||
KBP208 | 2 | 800 | 80 | 1.1 | 2 | 5 | 1000 | KBP | |||
KBP210 | 2 | 1000 | 80 | 1.1 | 2 | 5 | 1000 | KBP | |||
KBP306 | 3 | 600 | 110 | 1.1 | 3 | 5 | 1000 | KBP | |||
GBJ810 | 8 | 1000 | 175 | 1 | 8 | 5 | 1000 | GBJ | |||
GBJ1006 | 10 | 600 | 175 | 1 | 10 | 5 | 1000 | GBJ | |||
GBJ1008 | 10 | 800 | 175 | 1 | 10 | 5 | 1000 | GBJ | |||
GBJ1010 | 10 | 1000 | 175 | 1 | 10 | 5 | 1000 | GBJ | |||
GBJ1506 | 15 | 600 | 200 | 1 | 15 | 5 | 1000 | GBJ | |||
GBJ1508 | 15 | 800 | 200 | 1 | 15 | 5 | 1000 | GBJ | |||
GBJ1510 | 15 | 1000 | 200 | 1 | 15 | 5 | 1000 | GBJ | |||
GBJ2006 | 20 | 600 | 240 | 1 | 20 | 5 | 1000 | GBJ | |||
GBJ2008 | 20 | 800 | 240 | 1 | 20 | 5 | 1000 | GBJ | |||
GBU2510 | 25 | 1000 | 350 | 1 | 25 | 10 | 1000 | GBU | |||
GBU2508 | 25 | 800 | 350 | 1 | 25 | 10 | 1000 | GBU | |||
GBU2506 | 25 | 600 | 350 | 1 | 25 | 10 | 1000 | GBU | |||
GBU2010 | 20 | 1000 | 240 | 1 | 20 | 5 | 1000 | GBU | |||
GBU2008 | 20 | 800 | 240 | 1 | 20 | 5 | 1000 | GBU | |||
GBU2006 | 20 | 600 | 240 | 1 | 20 | 5 | 1000 | GBU | |||
GBU1506 | 15 | 600 | 220 | 1 | 15 | 5 | 1000 | GBU | |||
GBU1508 | 15 | 800 | 220 | 1 | 15 | 5 | 1000 | GBU | |||
GBU1510 | 15 | 1000 | 220 | 1 | 15 | 5 | 1000 | GBU | |||
GBJ3510 | 35 | 1000 | 350 | 1 | 35 | 5 | 1000 | GBJ | |||
GBJ5006 | 50 | 600 | 400 | 1 | 50 | 5 | 1000 | GBJ | |||
GBJ5008 | 50 | 800 | 400 | 1 | 50 | 5 | 1000 | GBJ | |||
GBJ5010 | 50 | 1000 | 400 | 1 | 50 | 5 | 1000 | GBJ | |||
KBJ406 | 4 | 600 | 135 | 1 | 4 | 10 | 1000 | KBJ | |||
KBJ408 | 4 | 800 | 135 | 1 | 4 | 10 | 1000 | KBJ | |||
KBJ410 | 4 | 1000 | 135 | 1 | 4 | 10 | 1000 | KBJ | |||
D2KB8 | 2 | 800 | 60 | 1.1 | 2 | 10 | 1000 | D3K | |||
KBJ1010 | 10 | 1000 | 210 | 1 | 10 | 10 | 1000 | KBJ | |||
KBJ1506 | 15 | 600 | 240 | 1 | 15 | 10 | 1000 | KBJ | |||
KBJ1508 | 15 | 800 | 240 | 1 | 15 | 10 | 1000 | KBJ | |||
KBJ1510 | 15 | 1000 | 240 | 1 | 15 | 10 | 1000 | KBJ | |||
KBJ2006 | 20 | 600 | 320 | 1 | 20 | 10 | 1000 | KBJ | |||
GBJ3508 | 35 | 800 | 350 | 1 | 35 | 5 | 1000 | GBJ | |||
GBJ3506 | 35 | 600 | 350 | 1 | 35 | 5 | 1000 | GBJ | |||
GBJ2510 | 25 | 1000 | 300 | 1 | 25 | 5 | 1000 | GBJ | |||
GBJ2010 | 20 | 1000 | 240 | 1 | 20 | 5 | 1000 | GBJ | |||
GBJ2506 | 25 | 600 | 300 | 1 | 25 | 5 | 1000 | GBJ | |||
GBJ2508 | 25 | 800 | 300 | 1 | 25 | 5 | 1000 | GBJ | |||
D2KB10 | 2 | 1000 | 60 | 1.1 | 2 | 10 | 1000 | D3K | |||
D3KB6 | 3 | 600 | 90 | 1.1 | 3 | 10 | 1000 | D3K | |||
D3KB8 | 3 | 800 | 90 | 1.1 | 3 | 10 | 1000 | D3K | |||
D3KB10 | 3 | 1000 | 90 | 1.1 | 3 | 10 | 1000 | D3K | |||
D4KB6 | 4 | 600 | 135 | 1.1 | 4 | 10 | 1000 | D3K | |||
D4KB8 | 4 | 800 | 135 | 1.1 | 4 | 10 | 1000 | D3K | |||
D4KB10 | 4 | 1000 | 135 | 1.1 | 4 | 10 | 1000 | D3K | |||
KBJ1008 | 10 | 800 | 210 | 1 | 10 | 10 | 1000 | KBJ | |||
KBJ1006 | 10 | 600 | 210 | 1 | 10 | 10 | 1000 | KBJ | |||
KBJ810 | 8 | 1000 | 200 | 1 | 8 | 10 | 1000 | KBJ | |||
KBJ808 | 8 | 800 | 200 | 1 | 8 | 10 | 1000 | KBJ | |||
KBJ806 | 8 | 600 | 200 | 1 | 8 | 10 | 1000 | KBJ | |||
KBJ606 | 6 | 600 | 170 | 1 | 6 | 10 | 1000 | KBJ | |||
KBJ608 | 6 | 800 | 170 | 1 | 6 | 10 | 1000 | KBJ | |||
KBJ610 | 6 | 1000 | 170 | 1 | 6 | 10 | 1000 | KBJ | |||
UD4KB100 | 4 | 1000 | 135 | 1.1 | 4 | 10 | 1000 | D3K | |||
KBJ2008 | 20 | 800 | 320 | 1 | 20 | 10 | 1000 | KBJ | |||
KBJ2010 | 20 | 1000 | 320 | 1 | 20 | 10 | 1000 | KBJ | |||
KBJ2506 | 25 | 600 | 350 | 1 | 25 | 10 | 1000 | KBJ | |||
KBJ2508 | 25 | 800 | 350 | 1 | 25 | 10 | 1000 | KBJ | |||
KBJ2510 | 20 | 1000 | 350 | 1 | 25 | 10 | 1000 | KBJ | |||
D2KB6 | 2 | 600 | 60 | 1.1 | 2 | 10 | 1000 | D3K | |||
UD6KB60 | 6 | 600 | 165 | 1 | 6 | 10 | 1000 | D3K | |||
UD6KB100 | 6 | 1000 | 165 | 1 | 6 | 10 | 1000 | D3K | |||
UD6KB80 | 6 | 800 | 165 | 1 | 6 | 10 | 1000 | D3K | |||
GBL406 | 4 | 600 | 125 | 1.1 | 4 | 10 | 1000 | GBL | |||
GBL408 | 4 | 800 | 125 | 1.1 | 4 | 10 | 1000 | GBL | |||
GBL410 | 4 | 1000 | 125 | 1.1 | 4 | 10 | 1000 | GBL | |||
GBL606 | 6 | 600 | 175 | 1.1 | 6 | 5 | 1000 | GBL | |||
GBL610 | 6 | 1000 | 175 | 1.1 | 6 | 5 | 1000 | GBL | |||
GBL608 | 6 | 800 | 175 | 1.1 | 6 | 5 | 1000 | GBL | |||
KBL406 | 4 | 600 | 125 | 1 | 4 | 10 | 1000 | KBL | |||
UD4KB80 | 4 | 800 | 135 | 1.1 | 4 | 10 | 1000 | D3K | |||
UD4KB60 | 4 | 600 | 135 | 1.1 | 4 | 10 | 1000 | D3K | |||
UD3KB100 | 3 | 1000 | 90 | 1.1 | 3 | 10 | 1000 | D3K | |||
UD3KB80 | 3 | 800 | 90 | 1.1 | 3 | 10 | 1000 | D3K | |||
UD3KB60 | 3 | 600 | 90 | 1.1 | 3 | 10 | 1000 | D3K | |||
UD2KB100 | 2 | 1000 | 60 | 1.1 | 2 | 10 | 1000 | D3K | |||
UD2KB80 | 2 | 800 | 60 | 1.1 | 2 | 10 | 1000 | D3K | |||
D6KB6 | 6 | 600 | 165 | 1 | 6 | 10 | 1000 | D3K | |||
D6KB8 | 6 | 800 | 165 | 1 | 6 | 10 | 1000 | D3K | |||
D6KB10 | 6 | 1000 | 165 | 1 | 6 | 10 | 1000 | D3K | |||
UD2KB60 | 2 | 600 | 60 | 1.1 | 2 | 10 | 1000 | D3K | |||
KBPC5016 | 50 | 1600 | 500 | 1.1 | 50 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC5012 | 50 | 1200 | 500 | 1.1 | 50 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC5010 | 50 | 1000 | 500 | 1.1 | 50 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC3516 | 35 | 1600 | 400 | 1.1 | 35 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC3512 | 35 | 1200 | 400 | 1.1 | 35 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC3510 | 35 | 1000 | 400 | 1.1 | 35 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC2516 | 25 | 1600 | 400 | 1.1 | 25 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC2512 | 25 | 1200 | 400 | 1.1 | 25 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC2510 | 25 | 1000 | 400 | 1.1 | 25 | 10 | 1000 | KBPC/KBPC-W | |||
KBL408 | 4 | 800 | 125 | 1 | 4 | 10 | 1000 | KBL | |||
KBL410 | 4 | 1000 | 125 | 1 | 4 | 10 | 1000 | KBL | |||
KBL606 | 6 | 600 | 150 | 1 | 6 | 10 | 1000 | KBL | |||
KBL608 | 6 | 800 | 150 | 1 | 6 | 10 | 1000 | KBL | |||
KBL610 | 6 | 1000 | 150 | 1 | 6 | 10 | 1000 | KBL | |||
KBU606 | 6 | 600 | 200 | 1 | 6 | 10 | 1000 | KBU | |||
KBU608 | 6 | 800 | 200 | 1 | 6 | 10 | 1000 | KBU | |||
KBU610 | 6 | 1000 | 200 | 1 | 6 | 10 | 1000 | KBU | |||
KBU806 | 8 | 600 | 300 | 1 | 8 | 10 | 1000 | KBU | |||
KBU808 | 8 | 800 | 300 | 1 | 8 | 10 | 1000 | KBU | |||
KBU810 | 8 | 1000 | 300 | 1 | 8 | 10 | 1000 | KBU | |||
KBU1006 | 10 | 600 | 300 | 1 | 10 | 10 | 1000 | KBU | |||
KBU1008 | 10 | 800 | 300 | 1 | 10 | 10 | 1000 | KBU | |||
KBU1010 | 10 | 1000 | 300 | 1 | 10 | 10 | 1000 | KBU | |||
KBPC1510 | 15 | 1000 | 300 | 1.1 | 15 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC1512 | 15 | 1200 | 300 | 1.1 | 15 | 10 | 1000 | KBPC/KBPC-W | |||
KBPC1516 | 15 | 1600 | 300 | 1.1 | 15 | 10 | 1000 | KBPC/KBPC-W |
