| Type | Datasheet | Circuit | Marking | IF | IFSM | VRRM | VF | IR | Trr | Package | |
| Max | Typ | ||||||||||
| A | A | V | V | V | μA | nS | |||||
| 重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | |||||||||
| YFWD305120CS |
|
|
YFW D305120CS | 9.5 | 46 | 1200 | 3 | 1.9 | 150 | / | TO-252 |
| YFWD306065AC |
|
|
YFW D306065AC | 11 | 18 | 650 | 1.8 | 1.59 | 120 | / | TO-220AC |
| YFWD308065AC |
|
|
YFW D308065AC | 14 | 55 | 650 | 2.4 | 1.57 | 200 | / | TO-220AC |
| YFWD308065FAC |
|
|
YFW D308065FAC | 11 | 25.5 | 650 | 2.4 | 2.1 | 200 | / | TO-220FAC |
| YFWD308065FCT |
|
|
YFW D308065FCT | 6 | 20 | 650 | 2.4 | 1.57 | 120 | / | TO-220F |
| YFWD310065AC |
|
|
YFW D310065AC | 15 | 65 | 650 | 1.8 | 1.61 | 220 | / | TO-220AC |
| YFWD310065CT |
|
|
YFW D310065CT | 15 | 65 | 650 | 1.8 | 1.61 | 220 | / | TO-220AB |
| YFWD310065DC |
|
|
YFW D310065DC | 15 | 65 | 650 | 1.8 | 1.61 | 220 | / | TO-263 |
| YFWD310065FAC |
|
|
YFW D310065FAC | 17.5 | 61 | 650 | 2 | 1.66 | 200 | / | TO-220FAC |
| YFWD310120AC |
|
|
YFW D310120AC | 16 | 26 | 1200 | 3 | 2 | 4000 | / | TO-220AC |
| YFWD313065CS |
|
|
YFW D313065CS | 16 | 82 | 650 | 2.4 | 2 | 300 | / | TO-252 |
| YFWD315065AC |
|
|
YFW D315065AC | 18 | 145 | 650 | 2.4 | 2 | 220 | / | TO-220AC |
| YFWD320065PT |
|
|
YFW D320065PT | 15 | 71 | 650 | 2.4 | 1.7 | 200 | / | TO-247 |
| YFWD320120PT |
|
|
YFW D320120PT | 16.5/33 | 59.5* | 1200 | 3 | 2.2 | 52 | / | TO-247 |
